GBP 57 ​ “Hold fast” − pot magnets, AlCo Max III To lift the magnet from the component via a press release spindle. With 2 tapped holes M8 for fixing brackets. ⌀ mm 44 55 70 08 5968 08Q “Hold fast” pot magnet AlNiCo eShop eShop eShop Remove the keeper Nominal clamping force N 200 400 880 plate before use. Magnet body height mm 44.5 49.2 64.5 Weight kg 0.6 1 2 ​ Suction lifter 08 6200 – Bridge handle for one-hand operation, for quick and efficient work. 08 6201 – Veribor® 2-head plastic suction lifter. Improved grip area made of non-slip rubber prevents slipping of the 08 6200_1 hand when carrying. With proven toggle lever technology. 08 6202 – Veribor® pump suction lifter made of plastic. Integrated pump tappet for quick and easy operation. With vacuum safety display with yellow ring on the pump tappet. 08 6203 – With proven toggle lever technology. 08 6200/6203 – Veribor® suction lifter made from sturdy aluminium, with rubber vacuum cups for a long working life. Application: For lifting materials with smooth, grease-free, and air-tight surface finishes. 08 6201_2 Note: 08 6200/6203 – Suction lifter should be released for storage, so that the rubber cups do not deform permanently. 08 6203_3 Type 1 2 3 08 6200 Suction lifter, aluminium eShop – – 08Z 08Z 08Z 08 6201 Suction lifter, plastic – eShop – 08 6203_2 08 6203 Suction lifter, aluminium – eShop eShop Suction head ⌀ mm 120 maximum load capacity kg 30 60 100 Type 1 08 6202 Pump suction lifter, plastic eShop 08Z Suction head ⌀ mm 210 08 6202_1 maximum load capacity kg 120 ​Girder clamp and sheet metal clamp Girder clamp for attaching to T-girders or H-profile girders. Approved for the transport of personnel. Girder clamps act as the attachment point for hoists, diverter rollers or work platforms. Load capacity t 1 2 08 6026 CORSO™ girder clamp eShop eShop 08Y 08 6026 Manufacturer‘s designation LT-1B LT-2B Weight kg 4.8 5.6 The clamp is opened and closed using the locking lever. The safety lock prevents the clamp from slipping from the material being transported, even without pulling load. Application: For the vertical transport of individual sheet metals and switching panels, profiles, and steel constructions. Note: The surface hardness of the material being transported must be less than HRC 30! The weight of the load to be lifted must not be less than 10 % of the given lifting capacity. Further sizes and types on request. 08 6032 Safe working load t 1,5 2 3 4 6 08 6032 Sheet metal clamp TBL plus (eShop) (eShop) (eShop) (eShop) (eShop) 08Y Gripping range mm 0 – 20 0 – 32 0 – 32 0 – 32 0 – 50 Weight kg 3 9.3 9.3 11.2 20.6 ​ Hand-operated winches and hoists Multi-purpose hoist with additional basic accessories consisting of lever tube, 20 m rope with tip and grommet, wound on to a manual reel. Note: Further multi-purpose hoists (e. g. “Jockey”) and accessories available on request. 08 Safe working load t 0,8 1,6 3,2 08 6021 Multi-purpose hoist with basic accessories (eShop) eShop (eShop) 08Y Manufacturer‘s designation T 508D T 516D T 532D Lever tube weight kg 1 2.4 2.4 Multi-purpose hoist weight kg 6.6 13.5 24 08 6021 1179
