GBP 57 ​ Cylindrical magnets, AlCo Max III ■ Cylindrical form, notch marking of polarity. ■ Magnetic material temperature-resistant up to maximum 550 °C (paint finish 100 °C). ■ Bar magnets can be extended by lining them up together. ⌀×Length mm 6×20 8×25 10×30 Cylindrical magnet 08 5936 AlNiCo 08 5936 ​ 02A eShop eShop eShop Set 2 pieces ​ Pot magnets, AlCo Max III ■ Machining the steel jacket will not impair magnet performance. Thread M6 ■ Magnetic force directed downwards as cased in an aluminium ring. Alu pot ■ Tapped hole in the magnet top face, for fastening. ■ Magnetic material temperature-resistant up to maximum 220 °C. Steel jacket Magnetic core Application: Incorporation in jigs, for holding or lifting. ⌀ mm 17 21 27 08 5940 AlNiCo 02A Pot magnet with keeper plate eShop eShop eShop Nominal clamping force N 26.5 40 61 Height mm 16 19 25 Remove the keeper plate before use. Tapped attachment hole in the magnet head mm M6 ​ Flat pot magnets, AlCo Max III ■ Flat magnet in a protective steel jacket. Steel housing Magnetic core ■ Magnet fixed from below via countersunk hole. ■ Magnetic material temperature-resistant up to maximum °C (size 19 up to 100 °C). Application: Jigs and fixtures. Hole with countersink ⌀ mm 19 29 38 08 5944 AlNiCo 02A Flat pot magnet with keeper plate eShop eShop eShop Nominal clamping force N 30 50 130 Attachment hole ⌀ mm 4.5 5.2 5.2 Remove the keeper plate before use. Height mm 7.5 8.7 10.35 ​ Button magnets, AlCo Max III ■ Round magnet with split adhesion surface and bore. Hole Magnet ■ Magnetic material temperature-resistant up to maximum 550 °C. Application: ■ For use with dial gauges. ■ Fixing of small metal objects. ⌀ mm 13 19 25 32 08 5946 AlNiCo 02A Button magnet with keeper plate eShop eShop eShop eShop Nominal clamping force N 7 19 34 48 Attachment hole ⌀ mm 4.4 4.8 4.8 7.1 Remove the keeper Height mm 9.5 12.7 15.9 25.4 plate before use. ​ Magnetic container 08 5904 – Plastic container with powerful permanent magnet. Ideally suited for placing as a lubricant pot in a CNC machine and as a magnetic tray. 08 5905 – Stainless steel container with powerful permanent magnets. 08 5906 – Plastic container with powerful permanent magnets. Special shape for use on vertical walls. 08 5905_150 08 5904 Application: For safe storage of small components, tools, fasteners etc. Magnetisable small components are stored safely, even in the upright position. 08 5905 _240×140 08 08 5905 _360×160 Container ⌀ or length×width mm 75 110 150 240×140 360×160 08 5904 02A Plastic magnetic lubricant pot eShop – – – – 08 5905 02A Stainless steel magnetic tray – – eShop eShop eShop 08 5906 02A Plastic magnetic tray – eShop eShop – – Number of magnets per container 1 1 1 2 3 08 5906 _110 08 5906 _150 1176
