GBP 57 For removal of oil, grease, grinding fluids, polishing fluids, paint residues, flux, oxide layers, carbon deposits, scale from nearly all surfaces and even from inaccessible places, whilst treating the component being cleaned with the utmost care. Use special power cleaner depending on the dirt and effectiveness required. The component to be cleaned must be completely surrounded by cleaning fluid. The ultrasonic cleaning devices from the Elmasonic Easy series are powerful and ideal for beginners. ■ 2 ultrasonic modes. ■ Temperature can be adjusted in steps of 5°C. ■ Electronic selector switch and LED display of all operating statuses. ■ Acoustic and visual feedback about the operating status. ■ Tray made of drawn stainless steel. Supplied with: Without component basket. 08 2003_3 Type 1 3 6 12 18 30 Ultrasonic cleaning unit 08 2003 eShop eShop eShop eShop eShop eShop 04S Elmasonic Easy Manufacturer‘s designation Elmasonic Easy 1L Elmasonic Easy 3L Elmasonic Easy 6L Elmasonic Easy 12L Elmasonic Easy 18L Elmasonic Easy 30L Volume l 0.9 2.7 5.9 12.9 17.8 27.5 Item length mm 235 305 370 380 405 575 Item width mm 135 190 225 315 375 375 Length of component basket mm 155 195 255 250 280 450 Width of component basket mm 70 105 105 195 255 255 Cleaning bath height mm 55 95 145 195 195 195 Heating power W 60 200 400 800 800 1200 Nominal voltage V 220 – 240 Weight kg 2 3.3 5.1 7.5 8.5 11 Recommended working volume l 0.7 1.2 4.3 10 14.2 22 ​ Ultrasonic cleaning accessories Rinsing unit ​ The new Elma Sink is an important addition to the overall cleaning process. Once the cleaning process in the ultrasonic unit is complete, the component basket can be inserted directly into the Elma Sink. This will ensure that any residues and cleaning chemicals are rinsed off – thoroughly. In conjunction with a suitable rinsing medium, this guarantees optimal cleaning results. Type S M L XL 08 2004 Rinsing unit (eShop) (eShop) (eShop) (eShop) 04S Manufacturer‘s designation Elma Sink S Elma Sink M Elma Sink L Elma Sink XL Volume l 3.9 5.9 17.8 27.5 Item length mm 305 365 395 565 Item width mm 155 170 315 315 Cleaning bath length mm 215 280 300 475 Cleaning bath width mm 115 130 270 270 Cleaning bath height mm 220 145 195 195 Weight kg 2 2.8 4.7 6.1 08 2004_5 Recommended working volume l 2.9 4.3 14.2 22 Drying unit ​ Elma Dry drying units are designed for use in production facilities, workshops and service areas. After cleaning in the ultrasonic bath, the items in the Elma component basket are first rinsed in the Elma Sink (No. 082004) and then dried easily and conveniently in the Elma Dry. Its cold/hot-air blower (70°C) ensures that even delicate parts can be dried gently. In cold-air mode, the parts can also be cooled down quickly. The cover includes ventilation slits that maximise the air turbulence and discharge the humid air to the outside. At the same time, the cover reduces energy consumption. The dust filter on the underside of the base is replaceable and prevents recontamination of the cleaned parts due to dust in the room air (filter fineness 33ppi). Due to the safety shutdown when the limit temperature is reached, Elma Dry units are both extremely safe and gentle on their contents. Type 3 12 30 08 2005 Drying unit (eShop) (eShop) (eShop) 04S Manufacturer‘s designation Elma Dry 30 Elma Dry 120 Elma Dry 300 Volume l 3 12 30 Item length mm 300 362 568 Item width mm 186 285 347 Length of component basket mm 220 275 475 Cleaning bath height mm 95 195 195 Heating power W 480 550 1100 maximum temperature °C 70 Nominal voltage V 220 – 240 08 Weight kg 3.6 6.1 10.2 08 2005_3 Note You can find suitable accessories in our online shop under No. 08 2101, 08 2102, 08 2103 and 08 2105. Noise protection cover Component basket No. 08 2105_50 No. 08 2101_3 1132
