High-quality, universally usable lamps, with on/off switch, 3-m rubber connection cable. All HEDI® machine/workstation lamps come with table clamps, integrated magnet and 4 screws for flexible attachment of the lamp to a wide variety of surfaces as standard.
Classic machine lamp in wide-beam version. Lamp head can be rotated and swivelled 340° using the ball joint. IP IP
With exchangeable light source. 20 20
| Type | 3LED | 6LED | ||
| 08 1301 | Machine lamp | eShop | eShop |
08 1301 08 1302
| Light output | W | 4.6 | 6 |
| Illumination | lm | 480 | 621 |
Light colour cold white
Colour temperature K 6500
A fold-away lens allows the lamp to be quickly and easily switched over between spot and wide-beam illumination. Lamp head can be rotated and swivelled 340° using the ball joint. With exchangeable light source. Type 6LEDDUO
08 1302 Machine lamp DUO eShop
| Light output | W | 6 |
| Illumination | lm | 621 |
Light colour cold white
Colour temperature K 6500
IP 08 1300
Proven machine lamp with extremely sturdy lamp head, protected against splashed water and dust-tight, 64 08 1303
for professional use in tough working environments or use on and in machines. Radio interference suppression according to DIN EN 62493.
| Type | 9LED | 9LED-24V | 10LED | |||||
| 08 1300 | eShop | – | – | |||||
| 08 1303 | Machine lamp | – | eShop | – | ||||
| 08 1304 | – | – | eShop | |||||
| Nominal voltage | V | 230 | 24 | 250 | IP |
non-dazzling flood 64
Light focussing Focussed light beam Focussed light beam
beam
| Beam dispersion angle fixed | degrees | 60 | 60 | 150 | 08 1304 | |
| Light output | W | 9.9 | 9.9 | 10 | ||
| Illumination | lm | 1560 | 1140 | 1250 |
With 3 brightness levels for optimal illumination of the workplace; innovative design enables object to be assessed from above using the lamp, extended 600 mm flexible metal arm.
Type 9LED-BR 08 1305
08 1305 Machine lamp eShop
| Light output | W | 6 | IP | |
| Illumination | lm | 750 | 20 |
IP The “ROPE LIGHT” is a 25 m long, flicker-free and approved rope light with an output of 20,000 lumens. The 65 light can be used both for orientation and as a work light. The drum enables the light to be conveniently rolled up. ROPE LIGHT is operated at low voltage (48 V DC), so there is no risk of an electric shock if the rope is accidentally trapped or cut.
Note: To prevent overheating, always fully uncoil the rope light from the drum before you connect it to the power supply.
Type ROPE-LIGHT 08 1605 08 1605 Rope light eShop
| Illumination | lm | 20000 |
| Overall length | mm | 25000 |
Robust cordless inspection lamps with LED lamp head.
mirror 65×43 mm.
| 08 1621_10 | 08 1621_15 | 08 1621_20 | |||
| 08 1621 | LED inspection set | eShop | eShop | eShop |
