Ручные и измерительные инструменты Hoffmann Group 2026 - страница 1101

Workshop lamps

Planonlight LED-light black series is the most intense, most dense and most compact of the Planonlight work lights. Add-on variant with flexible fastening options for the most demanding industrial applications.

• Very high illumination intensity with 157 Lumen/Watt LEDs.
• Absolutely maintenance-free (with a long working life of 50,000 h).
• Very compact design makes it ideal for retrofitting and for use in very intricate machines.
• Very wide range of variants, with 8 different models (built-in versions on request).
• Flexible attachment: Flush fitted in-built or with suitable, adjustable attachment 081381 for 45° surface mounting.
• Improved and proven sealing principle with IP68 and IP69K (leak-free against emulsion). Note: Operating voltage 24 V DC – connection directly to

the mains (230 V/50 Hz) will damage the lamp beyond repair!Use transformer No. 081375 to connect to the mains.

08 1353_10 _15 _30

Revolutionary working area lamp with the latest LED technology. Almost double the light intensity in comparison to existing lighting systems, giving very high sharpness for contours and contrast. Due to the minimal installation height of 28 mm the PLANONLIGHT LED saves space in virtually every workstation.

• Very high light density over the entire area. waterproof
• Extremely high illumination of daylight quality, whilst remaining dazzle-free and flicker-free, with no stroboscopic effects.
• Steplessly dimmable (transformer not included). Dimmable transformer is available under No. 081376.
• Immersion-proof (IP68) even against aggressive emulsions (IP69K).
• Very easy to clean − smooth surface and low surface temperature (maximum 10 °C above ambient).
• Absolutely maintenance-free.
• Certified to UL standards − for world-wide use.
• Easy retrofitting by self-installation.
• Direct connection via an M12 machine plug connector or using the connecting cable supplied

Function: IP69K: Protected against continuous submersion in pressurised water (pressurised watertight) and protected against penetration by dust (dust-tight), also completely protected against touching.

Note: Operating voltage 24 V DC − connection directly to the mains (230 V/50 Hz) will damage the lamp beyond repair! Use transformer No. 081375 to connect to the mains.

Accessories for workshop lamps 08

08 1375 – Transformer cannot be dimmed. Suitable dimmable transformer on request. suitable for 08 1375
