GBP 57 ≤3µm DIN ISO JIS HPC 6359 7388-2 B6339 ​Side lock arbors Weldon − JIS B 6339 (MAS-BT) 30 2593/2591/2596/2606/2650/2655 – All shanks hard turned (for smooth running). Balancing quality G2.5 / 25,000 rpm. With coolant supply holes that can be plugged. 30 2605 – Coolant channel bore can be plugged with an O-ring. 30 2597/2607/2617/2657/2667 – All shanks fine bead blasted. Balancing quality G6.3 / 18,000 rpm. 30 2600–2605/2610/2660/2670 – All shanks burnished. Application: For clamping tools with side flats to DIN 1835 B and DIN 6535 HB. Optional extras: Pull studs (PS) No. 308760 − 308802. Pull stud wrenches No. 308820; 308835. Side lock arbors, Weldon ​ G 2.5 Form G 6.3 Form G 6,3 Form 25000 AD 15000 ADB 18000 AD min-1 min-1 min-1 30 2593 30 2600 30 2607 Clamping ⌀ D1 mm 6 8 10 12 14 16 18 20 25 32 Side lock arbor 30 2593 BT 30 short eShop eShop eShop eShop eShop eShop eShop eShop – – 31A Form AD with cooling channel bore Side lock arbors 30 2597 BT 30 short eShop eShop eShop eShop – eShop – eShop – – 32A Form AD Side lock arbor BT 30 30 2591 eShop eShop eShop eShop – eShop – eShop – – 31A Form AD with cooling channel bore A = 100 Side lock arbor 30 2596 BT 40 short eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop 31A Form ADB with cooling channel bore Side lock arbor 30 2607 BT 40 short eShop eShop eShop eShop – eShop – eShop eShop eShop 32A Form AD Side lock arbor 30 2600 BT 40 short eShop eShop eShop eShop eShop eShop – eShop eShop – 36E Form ADB Side lock arbor 30 2605 BT 40 short eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop 36E Form ADB with cooling channel Side lock arbor BT 40 30 2606 eShop eShop eShop eShop eShop eShop eShop eShop – – 31A Form ADB with cooling channel bore A = 100 Side lock arbor BT 40 30 2617 eShop eShop eShop eShop – eShop – eShop – – 32A Form AD A = 100 Side lock arbor BT 40 30 2610 eShop eShop eShop eShop eShop eShop eShop eShop – – 36E Form ADB A = 100 Side lock arbor 30 2650 BT 50 short eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop 31A Form ADB with cooling channel bore Side lock arbor 30 2657 BT 50 short eShop eShop eShop eShop – eShop – eShop eShop eShop 32A Form AD Side lock arbor 30 2660 BT 50 short (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) – (eShop) (eShop) (eShop) 36E Form ADB Side lock arbors BT 50 30 2655 eShop eShop eShop eShop eShop eShop eShop eShop – – 31A Form ADB with cooling channel bore A = 100 Side lock arbor BT 50 30 2667 eShop eShop eShop eShop – eShop – eShop – – 32A 30 Form AD A = 100 Side lock arbor BT 50 30 2670 eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop 36E Form ADB A = 160 Dimension A (30 2593, 30 2597) mm 50 50 50 55 55 63 63 70 – – Dimension A (30 2591) mm 100 100 100 100 – 100 – – – – Dimension A (30 2596, 30 2607, 30 2600, 30 2605) mm 50 50 63 63 63 63 63 63 90 100 Dimension A (30 2650, 30 2657) mm 63 63 70 80 55 80 63 80 100 105 Dimension A (30 2660) mm 63 63 63 80 80 80 – 80 100 105 ⌀ D mm 25 28 35 42 44 48 50 52 65 72 Spare clamping screw No. 30 9900 6 8 10 12 12 16 16 20 25 32 989
