GBP 57 G 2.5 ~ 3µm h6 ISO Form 25000 HSC HPC 7388-1 ADB min-1 S-λ® Shrink-fit chuck Power Shrink Chuck with SAFE-λOCK® − (formerly DIN 69871) Shrink-fit chuck for very high metal removal rates during high-performance cutting (HPC). The optimised design combines excellent stiffness with vibration damping. ation e d i n form k This protects the machine, spindle and tool. i l c . Deta n Safe-Loer milling ■ Safe-Lock tool pull-out protection prevents the tool being pulled out accidentally. o und o u n d ef ■ Higher metal removal rate due to higher speeds, higher feed rates and greater cutting depth. can b ■ Shorter machining times. ■ Runs more smoothly, which improves the surface quality and protects the tool, spindle and machine. ■ With tapped holes for balancing with screws. ■ With pluggable Cool Jet holes. ➎ ■ With length adjustment screw (adjustment path 10 mm). ➌ Application: For clamping tools with parallel shank to h6 tolerance ➏ with Safe-Lock ground surface. ➊ Suitable for all types of shrink-fit unit such as inductive, contact and hot air shrink-fit units. Optional extras: Pull studs (PS) No. 308600 − 308800, Key PS wrenches No. 308820 – 308835. characteristics: ➋ Shrink-fit units, accessories No. 354210 − 354450, ➊H  igh concentricity balancing screws set No. 309906 size 180. (< 0.003 mm). ➍ ➋ L ow tendency to vibrate due to For milling cutters with Safe-Lock clamping flat, optimised outer contour. see solid carbide milling cutters. ➌ S lim design at the tip. Note: Other shrink-fit chucks with Safe-Lock available on request. ➍ Very rigid shank. ➎C  ool-Jet as standard (can be re-locked). ➏ Safe-Lock. ⌀D ⌀D2 ⌀D1 4,5° LE ​ 30 2303 A Clamping range ⌀ D1 mm 6 8 10 12 14 16 18 20 25 32 Shrink-fit chuck SK 40 30 2303 (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) 34I Power Shrink Chuck with Safe-Lock ultra short ⌀ D1 mm 6 8 10 12 14 16 18 20 25 32 Dimension A mm 65 65 65 65 65 65 65 65 75 80 ⌀ D mm 29.5 29.5 34 34 37 37 43 43 50 50 ⌀ D2 mm 22 22 26.5 26.5 29.5 29.5 35.5 35.5 45.5 45.5 maximum clamping depth LE mm 36 36 42 47 47 50 50 52 58 58 Haimer pre-setting devices available from the Hoffmann Group. Precision and productivity in production. els r mod Othe equest. on r 30 UNO range VIO range 984
