Thread turning – overview of range

Thread standards for our catalogue range.

Special solutions and other thread standards can be provided upon request – simply contact us for more details!

Pitch of Pitch of Pitch of

Cutting sketch Profile Thread type full profile semi-profile partial profile Insert size Catalogue

page

mm TPI mm mm TPI

int. 1/4P external 0.5 – 6 0.5 – 5 11 – 22 846 / 847 / 850

60° 60° Metric

h internal 0.5 – 6 0.5 – 5 6 – 22 848 – 850

1/8P ext.

int. external 28 – 11 48 – 5 11 – 16 851 / 853

R 55° 55° inch

h internal 28 – 11 48 – 8 6 – 16 852 – 853

R ext.

int. external 2 – 6 16 – 22 855

30°

h 30° Trapezoidal

internal 2 – 6 16 – 22 855

ext.

int. 1/4P external 20 – 8 16 854

60° 60° UN

h internal 20 – 8 11 – 16 854

1/8P ext.

30° int. external 18 – 8 16 853

30° h 60° NPT

internal 18 – 8 11 – 16 853

90° 1°47’ ext.

int. R external 10 – 4 16 – 22 854

30° Round h 30° h DIN 405

R internal 10 – 4 16 – 22 854

ext.

Differentiation between full, partial

Carbide grades: and semi-profile:

Grade Application Description

designation

• Good tensile strength

O N Universal use for steel up to < 55 HRC burr-free and true to DIN/ISO gauge.

• AlTiN, multi-layer PVD coating

Garant Specially adapted for stainless steels

M S

27 HB8125 Also suitable for lnconel

when used with cutting oil

Garant Uncoated

HU8315 N Ti Especially for aluminium

and titanium alloys

Partial profile threading inserts cover a

wide range of different pitches.

However, they do not produce true to gauge threads

according to DIN/ISO, since the profile radius

does not match the respective pitch.

• TiAlN, PVD coating

Holex Especially for steel and low-alloy Semi-profile threading inserts cut

M S

HBF20 stainless steels the complete profile and deburr the tips

• Fully sintered of the thread flanks. The external or

internal ⌀ is not cut with the profile.
