GBP 57 HELI3MILL shoulder mill 90° for TD..1505.. ​ Spare part: Ltot Size 40/4–50/5 – Pack of insert screws No. 229696 1 L1 (IP20; 9.0 Nm). Size 63/5–125/9 – Pack of insert screws No. 229696 2 (IP20; 9.0 Nm). ⌀ DC ⌀ DS ​ 22 6488_40/4 ⌀ DC / number of 22 6488 L1 Ltot ⌀ Ds h6 Circular interpo- Circular interpo- Circular interpo- Ramping angle Ramping length 19D effective cutting lation milling ⌀ lation milling ⌀ lation milling ap αmax L for αmax edges Z Dmin Dmax HELI3MILL shoulder mill mm Plain shank mm mm mm mm mm mm degrees mm 40/4 eShop 30 130 32 75 79 4 2.1 33 50/4 eShop 40 130 32 95 99 3.9 1.6 43 Ltot ⌀ DC ​ 22 6490_63/6S ⌀ DC / number of 22 6490 Ltot Mounting bore Circular interpo- Circular interpo- Circular interpo- Ramping angle Ramping length 19D effective cutting ⌀ lation milling ⌀ lation milling ⌀ lation milling ap αmax L for αmax edges Z Dmin Dmax HELI3MILL shoulder mill mm with bore mm mm mm mm mm degrees mm 40/4 eShop 40 16 75 79 4 2 33 50/4 eShop 40 22 95 99 3.9 1.6 43 50/5 eShop 40 22 95 99 3.9 1.6 43 63/5 eShop 45 22 121 125 3.8 1.2 56 63/5S eShop 45 27 121 125 3.8 1.2 56 63/6 eShop 45 22 121 125 3.8 1.2 56 63/6S eShop 45 27 121 125 3.8 1.2 56 80/5 eShop 50 27 155 159 3.7 0.9 73 80/6 eShop 50 27 155 159 3.7 0.9 73 80/7 eShop 50 27 155 159 3.7 0.9 73 100/6 eShop 50 32 195 199 3.6 0.7 93 22 100/8 125/7 eShop eShop 50 63 32 40 195 245 199 249 3.6 3.3 0.7 0.5 93 118 125/9 eShop 63 40 245 249 3.3 0.5 118 ToolScout ■ Quick application-related tool selection. ■ Available to order directly from the Hoffmann Group eShop. ■ Manufacturer and standard-related tool selection. ■ Cutting data - direct selection. ■ Tool information for reliable engineering. You can find optimum cutting data, machining strategy and NC programs for your machine programming in the ThreadScout. www.toolscout.com 698
