GBP 57 90° MEV 90° indexable milling cutter for indexable inserts TOMT060508 High-performance milling cutter with newly developed triangular indexable insert for corner and slot milling and ramping with lower cutting forces and increased stability. ⌀D ⌀ Ds L1 Ltot 22 6400 ⌀ D / number of 22 6400 maximum L1 Ltot ⌀ Ds Insert screw 25O teeth Z cutting depth h6 Indexable milling cutter ap max 90° MEV mm Plain shank mm mm mm mm ​ 20/2 eShop 6 26 110 16 229723 1 (10IP; 2.0 Nm) 20/2L eShop 6 40 150 20 229723 1 (10IP; 2.0 Nm) ⌀D M 25/3 eShop 6 29 120 20 229723 1 (10IP; 2.0 Nm) 25/2L eShop 6 50 170 25 229723 1 (10IP; 2.0 Nm) 22 6410 32/4 eShop 6 32 130 25 229723 1 (10IP; 2.0 Nm) Ltot 32/2L eShop 6 65 200 32 229723 1 (10IP; 2.0 Nm) 40/5 eShop 6 50 150 32 229723 1 (10IP; 2.0 Nm) 50/5 eShop 6 40 120 32 229723 1 (10IP; 2.0 Nm) ⌀ D / number of 22 6410 maximum Ltot Mounting Insert screw 25O teeth Z cutting depth thread M Indexable milling cutter ap max 90° MEV mm with threaded shank mm mm ​ ​ 20/3 eShop 6 30 M10 229723 1 (10IP; 2.0 Nm) 25/3 eShop 6 35 M12 229723 1 (10IP; 2.0 Nm) ⌀D 32/4 eShop 6 40 M16 229723 1 (10IP; 2.0 Nm) ⌀ D / number of 22 6420 maximum Ltot Mounting bore Insert screw 25O teeth Z cutting depth ⌀ Indexable milling cutter ap max 90° MEV Ltot mm with bore mm mm mm ​ 32/4 eShop 6 35 16 229723 1 (10IP; 2.0 Nm) 22 6420 40/5 eShop 6 40 16 229723 1 (10IP; 2.0 Nm) 50/5 eShop 6 40 22 229723 1 (10IP; 2.0 Nm) ​ Indexable inserts TOMT060508 for 90° indexable milling cutters MEV No. 226400 / 226410 / 226420 Improved chip evacuation with unique chip breaker design for the indexable inserts. The maximum axial rake angle of 17° ensures low cutting forces. Application: 22 6430/6436/6442 – The GM geometry is the 1st choice for general machining. 22 6433/6439/6445 – The SM geometry is the 1st Choice for lower cutting forces. 22 Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M S N ​ ​ ​ ​ ​ ​ PR1525 200 180 160 140 140 ○ ○ ● ● PR1535 200 160 ○ ○ ● ● CA6535 40 ○ ○ ● ● 22 6430 22 6436 22 6442 Type ST1400 INOX S 22 6430 TOMT 060508ER-GM PR1525 eShop – – 10 25A 25A 25A 25A 25A 25A 22 6433 TOMT 060508ER-SM PR1525 eShop – – 10 22 6436 TOMT 060508ER-GM PR1535 – eShop – 10 22 6439 TOMT 060508ER-SM PR1535 – eShop – 10 22 6442 TOMT 060508ER-GM CA6535 – – eShop 10 22 6445 TOMT 060508ER-SM CA6535 – – eShop 10 fz (22 6430, 22 6436, 22 6442) mm 0.08 – 0.25 0.08 – 0.2 0.08 – 0.2 ​ fz (22 6433, 22 6439, 22 6445) mm 0.08 – 0.2 0.08 – 0.15 0.08 – 0.15 ​ 696
