GBP 57 90° 90° indexable milling cutter MFWN for indexable inserts WNMU 0806.. Milling cutter with double-sided indexable inserts. The combination of approach angle, chip chamber design as well as the geometries and cutting angles of the indexable inserts ensure outstanding metal removal rates, chip clearance, working life, and low cutting forces, and hence high cost-effectiveness. Size 160/8–250/14 – Without internal cooling. Ltot L1 ⌀D/ 22 5600 maximum L1 Ltot ⌀ Ds h6 Insert screw 25O number of cutting depth ⌀ Ds teeth Z Indexable milling cutter ap max ⌀D 90° MFWN mm Plain shank mm mm mm mm ​ 22 5600_50/3 50/3 eShop 8 30 110 32 229700 (T15; 4.2 Nm) 63/4 eShop 8 30 110 32 229700 (T15; 4.2 Nm) 80/5 eShop 8 30 110 32 229700 (T15; 4.2 Nm) ⌀D/ 22 5615 maximum Ltot Mounting Insert screw Shim 25O number of cutting depth bore ⌀ teeth Z Indexable milling cutter ap max 90° MFWN Ltot mm with bore mm mm mm ​ ​ 50/4 eShop 8 40 22 229700 (T15; 4.2 Nm) – 63/3 eShop 8 40 22 229700 (T15; 4.2 Nm) 229751 63/4 eShop 8 40 22 229700 (T15; 4.2 Nm) – 63/5 eShop 8 40 22 229700 (T15; 4.2 Nm) – 80/4 eShop 8 50 27 229700 (T15; 4.2 Nm) 229751 80/5 eShop 8 50 27 229700 (T15; 4.2 Nm) – 80/7 eShop 8 50 27 229701 (T15; 3.5 Nm) – 100/5 (eShop) 8 50 32 229700 (T15; 4.2 Nm) 229751 ⌀D 100/7 eShop 8 50 32 229700 (T15; 4.2 Nm) – 100/9 (eShop) 8 50 32 229701 (T15; 3.5 Nm) – 125/6 (eShop) 8 63 40 229700 (T15; 4.2 Nm) 229751 125/8 eShop 8 63 40 229700 (T15; 4.2 Nm) – 125/12 (eShop) 8 63 40 229701 (T15; 3.5 Nm) – 160/8 (eShop) 8 63 40 229700 (T15; 4.2 Nm) 229751 160/10 (eShop) 8 63 40 229700 (T15; 4.2 Nm) – 160/14 (eShop) 8 63 40 229701 (T15; 3.5 Nm) – 22 5615_80/5 200/10 (eShop) 8 63 60 229700 (T15; 4.2 Nm) 229751 200/12 (eShop) 8 63 60 229700 (T15; 4.2 Nm) – 250/12 (eShop) 8 63 60 229700 (T15; 4.2 Nm) 229751 250/14 (eShop) 8 63 60 229700 (T15; 4.2 Nm) – Indexable inserts WNMU.. for indexable milling cutter No. 225600 / 225615 MEGACOAT-coated indexable inserts with 6 edges − due to double-sided version. The high axial rake angle up to a maximum of 13° significantly reduces the cutting force. 22 5627–5630 – Ground version for significantly better surface quality. Application: 22 5621 – The GH geometry is the first choice for roughing applications. 22 22 5620/5626 – The GM geometry is the first choice for general machining. 22 5623/5625 – The SM geometry has a highly positive rake and cuts smoothly. 22 5627–5630 – The GL geometry is suitable for good surface finishes thanks to the ground version and flat cutting edge. Note: Standard application values for ae = 0.3×D. 22 5620_ST1400 Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M S K ​ ​ ​ ​ ​ ​ PR1525 200 180 160 140 140 160 150 ● ○ ○ ● ● PR1535 160 150 ○ ○ ● ● PR1510 50 180 ○ ○ ● ● CA6535 240 200 40 ○ ○ ● ● fz Type ST1400 INOX GG S UNI mm 22 5620 WNMU 080608 EN-GM PR1525 eShop – – – – 10 0.1 − 0.3 25A 25A 25A 25A 25A 25A 25A 25A 22 5621 WNMU 080608 EN-GH PR1525 eShop – – – – 10 0.2 − 0.4 22 5623 WNMU 080608 EN-SM PR1525 – eShop – – – 10 0.06 − 0.2 22 5625 PR1535 – eShop – – – 10 0.06 − 0.2 22 5626 WNMU 080608 EN-GM PR1510 – – eShop – – 10 0.1 − 0.3 22 5627 PR1510 – – eShop – – 10 0.06 − 0.2 22 5628 WNEU 080608 EN-GL CA6535 – – – eShop – 10 0.06 − 0.1 22 5630 PR1525 – – – – eShop 10 0.06 − 0.15 694
