GBP 57 POWER CARD 45° 45° Indexable chamfer mill 45° for TC.T 110204 / 16T304 Note: Size 10 – Use GARANT torque screwdriver TQ No. 211750 size 3.0 45° with bit No. 674252 size 15IP. Size 1; 6 – Use GARANT torque screwdriver TQ No. 211750 size 1.2 with bit No. 674252 size 8IP. ⌀ Dmax ⌀ D ⌀ DS L1 Ltot 21 6550 Type 21 6550 Number of ⌀D ⌀ Dmax L1 Ltot ⌀ Ds h6 suitable indexable insert Insert screw 21O cutting edges Z Chamfer mill45° Weldon shank ​ mm mm mm mm mm ​ ​ 1 eShop 1 1.2 16 20 70 12 216611 UNI 219795 1 (8IP; 1.2 Nm) 6 eShop 2 6.2 21 35 90 20 216611 UNI 219795 1 (8IP; 1.2 Nm) 10 eShop 2 10.4 32.5 42 100 25 216616 UNI 219844 (15IP; 3.0 Nm) POWER CARD 60° 60° Indexable chamfer mill 60° for TC.T 110204 / 16T304 Note: 60° Size 20 – Use GARANT torque screwdriver TQ No. 211750 size 3.0 with bit No. 674252 size 15IP. Size 5; 16 – Use GARANT torque screwdriver TQ No. 211750 size 1.2 with bit No. 674252 size 8IP. ⌀ Dmax ⌀ D ⌀ DS L1 Ltot 21 6552 Type 21 6552 Number of ⌀D ⌀ Dmax L1 Ltot ⌀ Ds h6 suitable indexable insert Insert screw 21O cutting edges Z Chamfer mill 60° Weldon shank ​ mm mm mm mm mm ​ ​ 5 eShop 1 5.4 16 20 70 12 216611 UNI 219795 1 (8IP; 1.2 Nm) 16 eShop 2 15.8 26 35 90 20 216611 UNI 219795 1 (8IP; 1.2 Nm) 20 eShop 2 20 35 39 100 25 216616 UNI 219844 (15IP; 3.0 Nm) 21 ​ Indexable inserts TCMT 11 / 16 With all-round chip breaker groove. Suitable for: 90° indexable forwards countersink No. 216610; NEW chamfer mill No. 216548; No. 216550 No. 216552; No. 216622. ​ 21 6611 Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M S K N ​ ​ ​ ​ ​ 21 6611/​6616 250 250 120 250 200 200 130 120 120 100 100 150 ● ○ Type UNI 21 6611 TCMT 110204-CR HB7035 eShop 10 21A 21A 21 6616 TCMT 16T304-CR HB7035 eShop 10 Corner radius mm 0.4 ​ ISO code indexable insert (21 6611) TCMT 110204-CR ​ ISO code indexable insert (21 6616) TCMT 16T304-CR ​ fz mm 0.1 ​ 654
