GBP 57 ​ Toolholder with ratchet With two-jaw chuck for clamping square shanks. Moveable T-handle with a grooves centred and at each end for engaging the retaining ball. Holder with stainless steel sheath. Ratchet is reversible and can also be locked. All-steel construction for high torque applications. Clamping jaws milled and hardened for high toughness and optimum surface hardness. 14 8701 Size 117 – Heavy-duty version for taps up to M20. 14 8701_110 With head-side hexagon with 22 mm jaw width. 14 8706 – With hexagon shank to DIN 3126, in all-steel version, for holding taps (M3 - M10). Application: 14 8701 – Suitable for tapping holes where access is difficult. 14 8706 – Ideal for repair and assembly work in mobile situations. 14 9001 – Suitable for tapping holes where access is difficult. 14 8701_117 Note: The square sizes of other tap and reamer sizes can be found in the tables in the respective Product Groups. 14 9001_250 With 2 adjustable jaws. With ratchet and adjustable T-handle − The specified dimensions relate to the particularly useful for tapping holes where access is difficult. smallest and largest diameter. Overall length mm 85 110 117 250 300 14 8701 Toolholder with ratchet All-steel eShop eShop eShop – – 11K Toolholder with ratchet 14 9001 All-steel – – – eShop eShop 11K long Capacity □ mm 2.5 – 5.5 4.5 – 8 8.5 – 12.5 2.5 – 5.5 4.5 – 8 for hand taps DIN 352 M3 − M10 M5 − M12 M13 − M20 M3 − M10 M5 − M12 Spare jaws No. 148712 size 85 110 117 85 110 Type 6,3C 6,3E 11,2E 14 8706 14 Adapter for toolholder All-steel eShop eShop eShop 11K 14 8706_6.3C Capacity □ mm 2.5 – 5.5 2.5 – 5.5 4.9 – 7 for hand taps DIN 352 M3 - M10 M3 - M10 M4.5 – M12 DIN 3126 DIN 3126 DIN 3126 Shank standard Form C Form E Form E Machine drive 6.3C (1/4 inch) 6.3E (1/4 inch) 11.2E (7/16 inch) 14 8706_6,3E ​ Pin vice Serrated brass handle, nickel-plated with two interchangeable collets for different diameters. With square clamping nut. 14 9150 Pin vice eShop 12L Capacity □ mm 0–3 14 9150 Overall length mm 110 Serrated brass handle, nickel-plated. Size 0-3 – With two collets for different diameters. Size 0-1; 1-2 – With one collet. 14 9160_0-1 / _1-2 Capacity □ mm 0-1 1-2 0-3 14 9160_0-3 14 9160 Pin vice eShop eShop eShop 12L Capacity □ mm 0–1 1–2 0–3 Overall length mm 74 74 105 367
