GBP 57 M h9 60° HSS-E- PM DIN 13 40° ≤2.5×D GARANT Master Tap blind hole machine tap Universal taps, designed for use in a wide spectrum of materials with high process reliability. ■ HSS-E-PM tool material for maximum wear resistance. ■ Reduced coefficient of friction due to the new high-performance coating. ■ Special geometry for optimum swarf evacuation. 13 5960 13 5962 – All sizes: Shank to DIN 376 (= shank ⌀ relieved); C DIN DIN ISO 1X ISO 2X thus suitable for greater operating depths. 371 376 4HX 6HX 3 13 5965 – With internal coolant feed. ≤ M10 ≥ M12 ≤ M1.4 ≥ M1.6 13 6152 – Form E (1.5-2 turns lead chamfer) 13 5960 Size M1–M1,4 – Corresponds to ISO 1X/4HX. 13 5960 Size M1,6–M30 – Corresponds to ISO 2X/6HX. 13 5962 C DIN ISO 2X 376 6HX 3 13 5965 C DIN DIN ISO 2X 371 376 6HX 3 ≤ M10 ≥ M12 L 13 6152 E DIN DIN ISO 2X 371 376 6HX ØD 1½ ≤ M10 ≥ M12 Ø DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H M M K N ​ ​ ​ ​ ​ ​ 13 5960–​13 5965 30 35 20 30 30 25 12 8 10 8 20 20 ● ● ● 13 6152 22 25 15 22 22 18 8 6 7 6 15 15 ● ● ● M 13 5960 13 5962 13 5965 13 6152 Thread pitch L ⌀ Ds □ Tapping hole 11I 11I 11I 11I 13 ⌀ GARANT Master Tap machine tap HSS-E-PM ​ ​ 13 5960 13 5962 13 5960 13 5962 ​ HSS-E-PM IC / HSS-E-PM HSS-E-PM Form C 13 5965 13 5965 Form C Form E Form C 6HX 13 6152 13 6152 6HX 6HX DIN 376 AlTiX AlTiX AlTiX AlTiX mm mm mm mm mm mm mm M1 eShop – – – 0.25 40 2.5 – 2.1 – 0.75 M1,1 eShop – – – 0.25 40 2.5 – 2.1 – 0.85 M1,2 eShop – – – 0.25 40 2.5 – 2.1 – 0.95 M1,4 eShop – – – 0.3 40 2.5 – 2.1 – 1.1 M1,6 eShop – – – 0.35 40 2.5 – 2.1 – 1.25 M1,7 eShop – – – 0.35 40 2.5 – 2.1 – 1.35 M1,8 eShop – – – 0.35 40 2.5 – 2.1 – 1.45 M2 eShop – – eShop 0.4 45 2.8 – 2.1 – 1.6 M2,2 eShop – – – 0.45 45 2.8 – 2.1 – 1.75 M2,3 eShop – – – 0.4 45 2.8 – 2.1 – 1.9 M2,5 eShop – – – 0.45 50 2.8 – 2.1 – 2.05 M2,6 eShop – – – 0.45 50 2.8 – 2.1 – 2.15 M3 eShop eShop – eShop 0.5 56 3.5 2.2 2.7 – 2.5 M3,5 eShop – – – 0.6 56 4 – 3 – 2.9 M4 eShop eShop – eShop 0.7 63 4.5 2.8 3.4 2.1 3.3 M4,5 eShop – – – 0.75 70 6 – 4.9 – 3.7 M5 eShop eShop – eShop 0.8 70 6 3.5 4.9 2.7 4.2 M6 eShop eShop eShop eShop 1 80 6 4.5 4.9 3.4 5 M7 eShop – – – 1 80 7 – 5.5 – 6 M8 eShop eShop eShop eShop 1.25 90 8 6 6.2 4.9 6.8 M10 eShop eShop eShop eShop 1.5 100 10 7 8 5.5 8.5 M12 eShop – eShop eShop 1.75 110 9 – 7 – 10.2 M14 eShop – eShop eShop 2 110 11 – 9 – 12 M16 eShop – eShop eShop 2 110 12 – 9 – 14 M18 eShop – – – 2.5 125 14 – 11 – 15.5 M20 eShop – eShop eShop 2.5 140 16 – 12 – 17.5 M22 eShop – – – 2.5 140 18 – 14.5 – 19.5 M24 eShop – eShop eShop 3 160 18 – 14.5 – 21 M27 eShop – – – 3 160 20 – 16 – 24 M30 eShop – – – 3.5 180 22 – 18 – 26.5 311
