Режущие и зажимные инструменты Hoffmann Group 2026 - страница 304

GBP 57 M 60° HSS-E- PM DIN 13 ISO 2X 6HX h6 DIN Standard 40° 1835 B ≤2.5×D Synchronised blind hole machine tap with internal coolant supply Sturdy version with right-hand helix and shank to DIN 1835-B.Special geometry for use on C machines with synchronised spindle drives. The tap is guided by the synchronised spindle on the machine. Special TiAlN-S coating for optimum tool life. For use with emulsion (fat content 3 13 5410 minimum 8%). 13 5415 – Form E (lead chamfer: 1.5 - 2 turns) for the deepest possible thread depths. E 13 5420 – With internal coolant supply for maximum tool life. Recommendation: For TOOLOX materials we recommend deviating from the DIN data (see 1½ 13 5415 table) by drilling the tapping hole ⌀ 0.05 to 0.3mm larger. Note: For use on synchronised spindles, the GARANT quick-change tapping chuck No. 338100 − 338121 with minimum length adjustment (MLA) C ensures very high process reliability. 3 13 5420 L ⌀D □ ⌀ DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H H H M M S ​ ​ ​ ​ ​ 13 5410–​13 5420 32 20 12 7 7 3 ● ● ● M 13 5410 13 5415 13 5420 Thread pitch L ⌀ Ds □ Tapping hole ⌀ 11H 11H 11H Machine tap for synchronised spindles HSS-E-PM Form C HSS-E-PM Form E HSS-E-PM IC / Form C TiAlN TiAlN TiAlN mm mm mm mm mm M3 eShop eShop – 0.5 70 6 4.9 2.5 M4 eShop eShop – 0.7 70 6 4.9 3.3 M5 eShop eShop eShop 0.8 70 6 4.9 4.2 M6 eShop eShop eShop 1 80 6 4.9 5 M8 eShop eShop eShop 1.25 90 8 6.2 6.8 M10 eShop eShop eShop 1.5 100 10 8 8.5 M12 eShop eShop eShop 1.75 110 12 9 10.2 M16 eShop eShop eShop 2 110 12 9 14 13 Synchro insert with ER collet base body Advantages: ■ Better thread quality. ■ Less risk of tool breakage. ■ Increased process reliability thanks to reduced axial forces and reduced load on the thread flanks. ■ Increases the life of the tap. Very flexible due to the ■ Modular design ensures flexibility in use. ER base body. ■ Easy handling thanks to the quick-change adapter. ■ Perfect price/performance ratio yields optimum performance at low procurement costs. Suitable for through-coolant up to 50 bar. Optimum Quick-change adapter ensures damping. shorter set-up times. Slender design, ideal where headstock clearances are limited. For further information see Clamping Technology, No. 33 8180 – 33 8186. 304
