GBP 57 M C 60° HSS-E- DIN ISO 2X h9 DIN DIN PM 13 6HX 371 376 3 ≤1.5×D ≤1.5×D ≤ M10 ≥ M12 Through and blind hole machine taps Sturdy version. Recommendation: For very hard steels, TOOLOX and HARDOX materials we recommend deviating from the DIN data (see table) by drilling the tapping hole ⌀ 0.05 ​ 13 2055 to 0.3 mm larger. For use only with a length compensation chuck − even on machines with synchronised spindle drives. L ØD Ø DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H H H H M N ​ ​ ​ ​ ​ 13 2055 12 7 2 4 3 2 15 ● M 13 2055 Thread pitch L ⌀ Ds □ Tapping hole ⌀ 11H Machine tap HSS-E-PM TiCN mm mm mm mm mm M4 eShop 0.7 63 4.5 3.4 3.3 M5 eShop 0.8 70 6 4.9 4.2 M6 eShop 1 80 6 4.9 5 M8 eShop 1.25 90 8 6.2 6.8 M10 eShop 1.5 100 10 8 8.5 M12 eShop 1.75 110 9 7 10.2 M16 eShop 2 110 12 9 14 M20 eShop 2.5 140 16 12 17.5 M B 60° HSS-E- PM DIN 13 ISO 2X 6HX h6 DIN Standard 4 1835 B ≤2.5×D Synchronised through hole machine taps Sturdy design with spiral point and shank to DIN 1835-B.Special geometry for use on machines with synchronised spindle drives. The tap is controlled by the synchronising spindle of the machine. 13 Special TiAlN coating for optimum tool life. For use with emulsion (fat content minimum 8%). Recommendation: For TOOLOX materials we recommend deviating from the DIN data (see ​ 13 2065 table) by drilling the tapping hole ⌀ 0.05 to 0.3 mm larger. Note: For use on synchronised spindles, the GARANT quick-change tapping chuck No. 338100 − 338121 with minimum length adjustment (MLA) ensures very T​­ he spiral point evacuates the high process reliability. swarf in the cutting direction. L ⌀D □ ⌀ DS Suitable for/ vc [m/min] ISO code N N N P P P P P H H H H H H H M M S ​ ​ ​ ​ ​ 13 2065 37 35 22 12 7 7 6 ● ● ● M 13 2065 Thread pitch L ⌀ Ds □ Tapping hole ⌀ 11H Machine tap for synchronised spindles HSS-E-PM TiAlN mm mm mm mm mm M3 eShop 0.5 70 6 4.9 2.5 M4 eShop 0.7 70 6 4.9 3.3 M5 eShop 0.8 70 6 4.9 4.2 M6 eShop 1 80 6 4.9 5 M8 eShop 1.25 90 8 6.2 6.8 M10 eShop 1.5 100 10 8 8.5 M12 eShop 1.75 110 12 9 10.2 M16 eShop 2 110 12 9 14 272
