GBP 57 ​ High-precision countersink 90° with unequal spacing Suitable for/ vc [m/min] ISO code N N N P P P P P H H H M M S K N N ​ ​ ​ ​ ​ ​ 15 0130/​0132 75 75 50 65 50 30 18 8 8 16 10 12 25 60 ○ ● ● ○ High-precision countersink 90° with unequal spacing h9 HSS DIN 3 335 C 90° 15 0130 All countersinks have 3 cutting edges. Special geometry with extremely unequal spacing and matching cutting edge preparation. Radially relief ground. Flutes ground from solid. Newly developed special TiAlN coating for long service life. h9 High-precision countersink, produced with tight manufacturing tolerances similar to DIN 335-C. 15 0132 – Three drive flats on the shank for use in a 3-jaw chuck. 15 0132 Advantage: Very smooth cutting throughout the entire countersinking operation. Shank with 3 drive flats. Chatter-free running for perfect results and optimum tool service life. Application: High-precision countersinks for production of exactly round 90° countersunk surfaces. Extremely unequal spacing L (cutting edges arranged ⌀ DC ⌀ DS at unequal intervals). External ⌀ 15 0130 15 0132 smallest L ⌀ Ds for countersunk for countersunk 11M 11M Dc countersink ⌀ screws ISO 2009, screws DIN 7991 High-precision countersink for holes from 2010, 7046, 7047 < 500 N Precision countersink with unequal spacing f with unequal spacing and 3 drive flats 90° mm TiAlN TiAlN mm mm mm ​ ​ mm/rev. 4,3 eShop eShop 1.3 40 4 M2 – 0.08 6 eShop eShop 1.5 45 5 M3 – 0.1 6,3 eShop eShop 1.5 45 5 – M3 0.1 8 eShop eShop 2 50 6 M4 – 0.1 8,3 eShop eShop 2 50 6 – M4 0.1 10 eShop eShop 2.5 50 6 M5 – 0.13 15 10,4 eShop eShop 2.5 50 6 – M5 0.13 11,5 eShop eShop 2.8 56 8 M6 – 0.13 12,4 eShop eShop 2.8 56 8 – M6 0.13 15 eShop eShop 3.2 60 10 M8 – 0.13 16,5 eShop eShop 3.2 60 10 – M8 0.18 19 eShop eShop 3.5 63 10 M10 – 0.18 20,5 eShop eShop 3.5 63 10 – M10 0.22 23 eShop eShop 3.8 67 10 M12 – 0.22 25 eShop eShop 3.8 67 10 – M12 0.25 31 eShop eShop 4.2 71 12 – M16 0.25 Sets of high-precision 90° countersinks h9 h9 HSS DIN 3 335 C 150301 150303 90° 150305 150307 15 0301 / 0305 – Precision countersink 150130. 15 0303 / 0307 – Precision countersink 150132. All countersinks also have 3 drive flats on the shank for use in a 3-jaw chuck. Advantage: Very smooth cutting throughout the entire countersinking operation. Chatter-free running for perfect results and optimum tool service life. Application: High-precision countersinks for production of precise, round 90° countersunk surfaces. Supplied with: 15 0301/0303 – 5-piece precision countersink set in a round box. 15 0305/0307 – 5-piece precision countersink set in a case. Number of countersinks 5 High-precision countersink set No. 150130 in a box 15 0301 11M TiAlN eShop 90° 15 0301 High-precision countersink set with 3 drive flats No. 150132 in a box 15 0303 11M TiAlN eShop 15 0303 90° Content: Size 6.3; 10.4; 12.4; 16.5; 1 pc. each countersink 20.5 Number of countersinks 5 High-precision countersink set No. 150130 in a case 15 0305 11M TiAlN eShop 90° High-precision countersink set with 3 drive flats No. 150132 in a case 15 0307 11M TiAlN eShop 90° 15 0305 Content: Size 6.3; 10.4; 16.5; 20.5; 15 0307 1 pc. each countersink 25 Case ​ for number of countersinks 5 15 0368 11M Empty case eShop 201
