GBP 57 5×D 6×D Magic Drill DRV indexable drill for right-hand cutting, plain shank with drive flat Indexable drill with excellent chip evacuation for drilling depths up to 6xD. Highly efficient machining with high cutting speeds thanks to the combination of a CVD outer insert and a PVD inner insert. Excellent drilling accuracy and low cutting pressure lead to the best drilling results. With plain shank with side drive flat. 23 6066 – Sizes 12 – 39: Bore tolerance: ⌀ DC 0 / +0.35 mm. NEW Sizes 40 – 60: Bore tolerance: ⌀ DC 0 / +0.40 mm. 23 6068 – Sizes 12 – 39: Bore tolerance: ⌀ DC 0 / +0.45 mm. Sizes 40 – 60: Bore tolerance: ⌀ DC 0 / +0.50 mm. Application: With indexable inserts No. 236070 to No. 236125. ​ 23 6066 Supplied with: Includes clamping screws and two additional replacement clamping screws (without indexable inserts). LA LS Attention: A disc falls off when the drill exits. Risk of injury if the component is rotating. Please take L1 safety precautions. Chamfering attachment and eccentric bush available on request. Recommendation: When drilling on sloping surfaces, semi-cylindrical holes, hollowing out holes, boring Ø DC V Ø DS out and chamfered holes, reduce the cutting speed to 120 m/min. A PVD indexable insert on the outer cutting edge is recommended for these machining operations. ⌀ DC 23 6066 23 6068 LA ⌀ Ds Ls ISO code Insert screw 25R 25R indexable insert Magic Drill DRV indexable drill Combination shank 23 6066 23 6068 ​ ​ ​ ​ mm 5×D 6×D mm mm mm mm ​ ​ 12 (eShop) (eShop) 60 72 20 43 LCMT0302.. 236135 10 (6IP; 0.5 Nm) 13 (eShop) (eShop) 65 78 20 43 LCMT0302.. 236135 10 (6IP; 0.5 Nm) 14 (eShop) (eShop) 70 84 20 43 SCMT0402.. 236135 10 (6IP; 0.5 Nm) 15 (eShop) (eShop) 75 90 20 43 SCMT0402.. 236135 10 (6IP; 0.5 Nm) 23 16 17 (eShop) (eShop) (eShop) (eShop) 80 85 96 102 25 25 54 54 SCMT0502.. SCMT0502.. 236135 20 (6IP; 0.5 Nm) 236135 20 (6IP; 0.5 Nm) 18 (eShop) (eShop) 90 108 25 54 SCMT0502.. 236135 20 (6IP; 0.5 Nm) 19 (eShop) (eShop) 95 114 25 54 SCMT0602.. 236135 30 (8IP; 1.2 Nm) 20 (eShop) (eShop) 100 120 25 54 SCMT0602.. 236135 30 (8IP; 1.2 Nm) 21 (eShop) (eShop) 105 126 25 54 SCMT0602.. 236135 30 (8IP; 1.2 Nm) 22 (eShop) (eShop) 110 132 25 54 SCMT0602.. 236135 30 (8IP; 1.2 Nm) 23 (eShop) (eShop) 115 138 25 54 SCMT0703.. 236135 40 (10IP; 2 Nm) 24 (eShop) (eShop) 120 144 25 54 SCMT0703.. 236135 40 (10IP; 2 Nm) 25 (eShop) (eShop) 125 150 25 54 SCMT0703.. 236135 40 (10IP; 2 Nm) 26 (eShop) (eShop) 130 156 25 54 SCMT0703.. 236135 40 (10IP; 2 Nm) 27 (eShop) (eShop) 135 162 32 59 SCMT0904.. 236135 50 (10IP; 2 Nm) 28 (eShop) (eShop) 140 168 32 59 SCMT0904.. 236135 50 (10IP; 2 Nm) 29 (eShop) (eShop) 145 174 32 59 SCMT0904.. 236135 50 (10IP; 2 Nm) 30 (eShop) (eShop) 150 180 32 59 SCMT0904.. 236135 50 (10IP; 2 Nm) 31 (eShop) (eShop) 155 186 32 59 SCMT0904.. 236135 50 (10IP; 2 Nm) 32 (eShop) (eShop) 160 192 32 59 SCMT0904.. 236135 50 (10IP; 2 Nm) 33 (eShop) (eShop) 165 198 40 69 SCMT1104.. 236135 60 (15IP; 3.5 Nm) 34 (eShop) (eShop) 170 204 40 69 SCMT1104.. 236135 60 (15IP; 3.5 Nm) 35 (eShop) (eShop) 175 210 40 69 SCMT1104.. 236135 60 (15IP; 3.5 Nm) 36 (eShop) (eShop) 180 216 40 69 SCMT1104.. 236135 60 (15IP; 3.5 Nm) 37 (eShop) (eShop) 185 222 40 69 SCMT1104.. 236135 60 (15IP; 3.5 Nm) 38 (eShop) (eShop) 190 228 40 69 SCMT1104.. 236135 60 (15IP; 3.5 Nm) 39 (eShop) (eShop) 195 234 40 69 SCMT1104.. 236135 60 (15IP; 3.5 Nm) 40 (eShop) (eShop) 200 240 40 69 SCMT1405.. 236135 70 (20IP; 4.5 Nm) 41 (eShop) (eShop) 205 246 40 69 SCMT1405.. 236135 70 (20IP; 4.5 Nm) 42 (eShop) (eShop) 210 252 40 69 SCMT1405.. 236135 70 (20IP; 4.5 Nm) 43 (eShop) (eShop) 215 258 40 69 SCMT1405.. 236135 70 (20IP; 4.5 Nm) 44 (eShop) (eShop) 220 264 40 69 SCMT1405.. 236135 70 (20IP; 4.5 Nm) 45 (eShop) (eShop) 225 270 40 69 SCMT1405.. 236135 70 (20IP; 4.5 Nm) 46 (eShop) – 230 – 40 69 SCMT1405.. 236135 70 (20IP; 4.5 Nm) 47 (eShop) – 235 – 40 69 SCMT1405.. 236135 70 (20IP; 4.5 Nm) 48 (eShop) – 240 – 40 69 SCMT1405.. 236135 70 (20IP; 4.5 Nm) 49 (eShop) – 245 – 40 69 SCMT1405.. 236135 70 (20IP; 4.5 Nm) 50 (eShop) (eShop) 250 300 40 69 SCMT1706.. 236135 80 (20IP; 4.5 Nm) 51 (eShop) – 255 – 40 69 SCMT1706.. 236135 80 (20IP; 4.5 Nm) 52 (eShop) – 260 – 40 69 SCMT1706.. 236135 80 (20IP; 4.5 Nm) 53 (eShop) – 265 – 40 69 SCMT1706.. 236135 80 (20IP; 4.5 Nm) 54 (eShop) – 270 – 40 69 SCMT1706.. 236135 80 (20IP; 4.5 Nm) 55 (eShop) (eShop) 275 330 40 69 SCMT1706.. 236135 80 (20IP; 4.5 Nm) 56 (eShop) – 280 – 40 69 SCMT1706.. 236135 80 (20IP; 4.5 Nm) 57 (eShop) – 285 – 40 69 SCMT1706.. 236135 80 (20IP; 4.5 Nm) 58 (eShop) – 290 – 40 69 SCMT1706.. 236135 80 (20IP; 4.5 Nm) 59 (eShop) – 295 – 40 69 SCMT1706.. 236135 80 (20IP; 4.5 Nm) 60 (eShop) (eShop) 300 360 40 69 SCMT1706.. 236135 80 (20IP; 4.5 Nm) 178
