GBP 57 ​Push-pull toggle clamp short type Hardened shoulder screws. 37 6700 – ■ Compact design due to new handle. ■ Ergonomic 2-component handle, very comfortable to use due to enlarged hand rest. 37 6725 – ■ Ergonomic handle made of oil-resistant plastic. Application: ■ Direct fixing to sheet metal fixing points. ■ Connected to jig body with threaded end of arm. Optional extras: 37 6700 – Angled base No. 376730. 37 6725 – Angled base No. 376735. 37 6700 Note: ■ Available in stainless steel on request. 37 6725 Type 2 3 5 37 6700 eShop eShop eShop 32S 35A Push-pull toggle clamp short body 37 6725 eShop eShop – Clamping range (37 6700) mm 21.5 40 67 Clamping range (37 6725) mm 19 38 – Clamping force P (pressure and traction) (37 6700) N 1000 2500 4000 Clamping force P (pressure and traction) (37 6725) N 900 1300 – Overall height H (37 6700) mm 73 123 149 Overall height H (37 6725) mm 74 100 – Overall length L (37 6700) mm 161.5 258 364 Overall length L (37 6725) mm 163 237 – Contact screw (37 6700) mm M6×25 M8×35 M12×50 Contact screw (37 6725) mm M6×40 M8×50 – thread at front of clamp mm M16×1.5 M20×1.5 M24×1,5 ​ Hook toggle clamp − heavy-duty version Base, lever arm, and catch of cast steel, pin of hardened steel. For high retaining force. 37 6840 Type 4 5 Hook toggle clamp 37 6840 eShop (eShop) 35A heavy-duty Hole spacing e mm 45 57 Hole spacing f mm 45 57 Bore ⌀ d mm 8.5 10.5 Adjustment travel of clamping hook c mm 24 – 90 28 – 93 Clamping height h mm 26 32 Clamping force P (traction) N 15000 27000 Overall height H mm 122 146 Overall length L mm 198 250 M ​ Contact screws with thread ■ Hardened, galvanised, passivated, strength 8.8. ■ Vulcanised, oil-resistant contact head (silicone-free). b L Application: To protect delicate components. k e 37 7050 Type 4×25 5×30 6×25 6×35 8×35 8×45 8×50 8×65 12×50 12×80 12×110 Contact screw 37 7050 eShop eShop eShop eShop eShop (eShop) eShop eShop eShop eShop eShop 35A with threaded shank L mm 32 38 35 45 48 58 63 78 70 100 130 b mm 24 28 23 33 32 42 47 62 46 76 106 k mm 8 10 12 12 16 16 16 16 24 24 24 e mm 11 13 16 16 21 21 21 21 31 31 31 Strength 8.8 ​ Protective caps for contact screws Oil-resistant rubber. Application: To protect delicate components. 37 Note: ■ 6/18 = 18 AF (new standard = marked 6 on the contact surface). ■ 6/19 = 19 AF (old standard). ■ Minimum order quantity each size 10 pieces. 37 7020 Type 0 1 2 3/4 4 6/18 6/19 37 7020 Protective cap eShop eShop eShop eShop eShop eShop eShop 35A for screws M4 M5 M6 M8 M10 M12 / 18 AF M12 / 19 AF ⌀ mm 11 12.5 15 19 22 25 26 Height mm 8.5 10 12 15 17.5 20 20 1252
