GBP 57 ​ Jack pads Quenched and tempered steel. 37 5030 – Specially designed as a centring aid for assembling several screw jacks together. Only for screw jack sizes 52, 70 and 100. 37 5000 Suitable for: Screw jacks and wedge blocks No. 373500 − 374900. Pad 37 5000 Ball pad eShop 35A 37 5010 Vee-pad eShop 35A 37 5010 External ⌀ (37 5000) mm 39 External ⌀ (37 5010) mm 45 Fixing attachment 37 5030 Centring pad for positioning screw jacks eShop 35A External ⌀ mm 45 37 5030 OUR PARTNER FOR CLAMPING ELEMENTS AND HAND TOOLS. The Hoffmann Group supplies the entire range containing over 14,000 items on short notice ex manufacturer’s stock. Order from the Hoffmann Group simply and conveniently using the HALDER item number. Over 85 years’ experience, an extensive product range and expert realisation of a wide range of customer requirements. Standard components Aerospace Hand tools ​ Frame clamp Clamping elements with replaceable jaws. Advantage: ■ Angled arrangement of the movable jaws creates a pull-down effect. ■ Solid construction of vibration-damping spheroidal graphite iron (GGG60). ■ Optimum compatibility to the workpiece. H 90±0,01 ■ Few interference contours. Supplied with: 1 pc. interchangeable jaw (serrated / smooth). 6 20 H7 M6 37 0135 L Type 1 2 52,5 37 0135 Frame clamp (eShop) – 37K B 17,5 37 0136 Frame stop – (eShop) 37K Length mm 185 200 Width mm 65 Height mm 135 132 maximum tightening torque Nm 50 37 0136 Clamping force kN 20 ​ Toe clamp Especially low-height and compact design. Pull-down effect due to oblique guidance wedge. Material: Quenched and tempered steel. S Application: For lateral clamping of particularly flat components directly on the jig insert. S 37 H H1 Thread M8 M12 M16 37 5006 Toe clamp (eShop) (eShop) (eShop) 37K M Width B mm 25 35 40 Clamping range mm 3 5 6 Height H mm 25 38 45 37 5006 Height H1 mm 15 23 25 Clamping force kN 7 20 40 maximum tightening torque Nm 25 90 200 1236
