GBP 57 ​ Steplessly adjustable clamps The clamp and Tee bolt form a single unit (no loose parts). The shape of the clamp provides for stepless adjustment without additional blocks. Material: Hardened, black, screw strength 8.8. Application: For quick and reliable clamping of various component heights on milling machines. Supplied with: Complete with T-bolt (No. 375301). Slot width a 37 0670 Clamping height h Length L Width B 32H Steplessly adjustable clamp mm mm mm mm 12 eShop 0 – 45 105 44 14 eShop 0 – 45 105 44 h 16 eShop 0 – 50 140 51 18 eShop 0 – 50 140 51 22 eShop 0 – 70 160 60 ​ Steplessly adjustable clamps, short ■ Stepless adjustment. ■ Hardened, black. Supplied with: U-piece, complete with T-bolt (No. 375301). Slot width a 37 0675 Clamping height h Length L Width B 32H h Steplessly adjustable clamp, short mm mm mm mm L 14 eShop 0 – 35 118 50 18 eShop 0 – 40 135 60 22 eShop 0 – 50 160 68 B 28 eShop 0 – 60 160 80 ​Clamps Material: 37 1000 – Quenched and tempered steel, painted. 37 1005 – Hardened, black. ​ 37 1000 37 1005 Slot width×overall length mm 7×50 6,6×50 9×60 11×80 14×100 14×125 18×125 18×160 22×160 22×200 26×200 26×250 37 1000 Clamp DIN 6314 eShop – eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop 35A 37 1005 32H Clamp – eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop eShop Height mm 10 10 12 15 20 20 25 25 30 30 30 35 Width mm 20 20 24 30 40 40 50 50 60 62 70 70 for clamping screws M6 M6 M8 M10 M12; M14 M12; M14 M16; M18 M16; M18 M20; M22 M20; M22 M24 M24 ​ Forked clamps with shoe − DIN 6315 GN Material: Quenched and tempered steel, painted. Slot width×overall 37 1400 Height Width for clamping screws 35A length Forked clamp with shoe mm DIN 6315 GN mm mm ​ 9×100 eShop 15 30 M8 37 11×125 14×160 14×200 eShop eShop eShop 20 25 25 30 40 40 M10 M12; M14 M12; M14 18×200 eShop 30 50 M16; M18 18×250 eShop 30 50 M16; M18 22×250 eShop 40 60 M20; M22 22×315 eShop 40 60 M20; M22 26×250 eShop 40 70 M24 26×315 eShop 40 70 M24 33×315 eShop 50 80 M30 33×400 eShop 50 80 M30 1232
