GBP 57 Pitbull clamps ​ ■ Clamp with socket-head screw to DIN912, with oil-tight O-ring. ■ Secure and precise clamping. ■ Compact size, so few interference contours. 37 0025 – Knife edge for blanks. 37 0030 – Blunt edge for general tasks. Application: Ideal for multiple clamping. 37 0025_M6 Knife Blunt 37 0030_M6 Thread M 37 0025 37 0030 BH9 H B1 H1 H2 Clamping width Clamping travel maximum tight- Clamping force Material 37M 37M ening torque Pitbull clamp knife edge blunt edge mm mm mm mm mm mm mm Nm kN ​ M2,5 eShop eShop 8 9.5 6.6 3.8 3.6 1.9 9.5 0.15 1.8 2.8 Steel M4 eShop eShop 8 12.7 9.9 5.1 4.8 2.6 12.7 0.4 5.6 6.6 Steel M6 eShop eShop 6 19.05 14.48 7.6 7.2 3.8 19.1 0.6 22.5 16 Steel M10 eShop eShop 4 25.4 18.03 10.2 11.4 6.3 25.4 1.7 40 26 Steel Clamping claws ​ D1 ■ The contour of the claw generates a slight pull-down force. ■ The low clamping height saves material. H ■ Higher cutting values due to positive clamping. L B 37 0034 Application: Ideal for multiple clamping. 37 0034 – For use as a stop in jigs in conjunction with Pitbull clamps No. 370025; 370030 or eccentric clamps No. 370001; 370005; 370008. D Supplied with: 1 clamping claw with screw. D1 H 37 0035 Type 37 0034 37 0035 Screw to standard ⌀D L B H ⌀ D1 recommended 37M 37M clamping height Ultra clamping claw, Versa clamping claw, rectangular round ​ mm mm mm mm ​ mm 1 eShop – 2 M5×12 – 19.05 12.7 6.35 for M5 1.5 – 1.9 2 eShop – 2 M5×12 – 19.05 19.05 7.92 for M5 1.5 – 3 3 eShop – 2 M5×12 – 19.05 25.4 7.92 for M5 1.5 – 3 4 (eShop) – 1 M8×16 – 25.4 25.4 12.7 for M8 1.5 – 5.6 5 – eShop 2 M5×10 19.05 – – 9.53 for M5 1.5 – 3 Our partner for standard parts The Hoffmann Group supplies the entire range on short lead times ex manufacturer’s stock. More than 75,000 items. Over 6,000 of them from the field of clamping technology. ■ All standard parts and consumables. ■ All modular clamping systems. ■ Special solutions to customer’s drawings available on request. Order from the Hoffmann Group simply and conveniently using the KIPP item number. And much more. . . Mix of universal KIPP clamping element products: Base elements and attachment elements for modular workpiece design: 37 1221
