GBP 57 ​ High-pressure machine vice ■ The base body with longitudinal and transverse slot ensures the vice is aligned quickly and precisely in both directions. ■ The maintenance-free high-pressure spindle ensures a constant pressure level thanks to a wear-resistant, fully mechanical power intensifier. ■ High-quality spheroidal cast iron with hardened, ground workpiece mounting face and precision-ground guides. ■ The desired clamping pressure can be preselected – without high pressure in position 0. ■ No loss of clamping force. ■ Interchangeable jaws, hardened and ground. ■ Height tolerance ± 0.03 mm. ■ Fast alignment with two loose tenons in the precisely manufactured vice slot. Application: ■ For vibration-free and absolutely reliable clamping with the highest possible cutting and feed rate forces. 36 2240 ■ The uniform support height allows efficient working with several vices at the same time. ■ The clamping action is performed using a crank. High clamping forces are achieved with minimal force in a maximum of two spindle revolutions. Supplied with: 4 table clamps, 1 pair smooth jaws, crank handle. L Optional extras: Swivel base No. 362260 125. d b c G L L a Jaw width 36 2240 Clamping Clamping Clamping Weight c d1 a L2 L3 L4 G +0.02 Colour code for 31O range b I range b II force suitable accessories High-pressure vice mm mm mm kN kg mm ​ mm mm mm mm mm 125 eShop 0 – 102 98 – 202 40 30 118 M8 427 85 45 508 – 710 78 ​ ​ Stationary machine vice Application: Versatile clamping unit for machining centres. Supplied with: Incl. 2 pcs. top jaws, 1 pc. front jaws No. 362181, Flexibility due to Wear resistant front strips. spindle. 1 pc. front jaws No. 362182 and 1 pc. hand crank. Optional extras: Front jaws No. 362177 – 362185, crank No. 362190, spare-parts set No. 362199. Mounted with Tee bolts No. 375300 and aligned with tenons No. 375365. Note: Alignment dimensions not compatible with those of other manufacturers. Size 100M; 150M – Metric version – screws and threads in metric version, drive hexagon = AF 19 mm (150M), drive hexagon = AF 14 mm (100M). Size 150I – Inch version – screws and threads in imperial version, drive hexagon = 3/4 inch AF. ​ 36 2175 Precision guide slots 20H7 Clamping using hand crank L2 b L1 A f C SW c L3 B Representation of the force transfer in the mobile Attachment options for front strips a jaw. 36 Type 36 2175 b Clamp- c +/- C A a B L1 L2 L3 f AF Colour code for 32P ing 0.012 suitable accessories force Stationary machine vice mm kN mm mm mm mm mm mm mm mm mm mm in ​ NEW 100M eShop 0 – 155 40 73 34.9 102 318 129 78.7 44.8 64 63.5 14 – – 150M eShop 0 – 232 36 73 44.5 151 427 186 101.6 58.7 90.5 98.4 19 – ​ 150I eShop 0 – 232 36 73 44.5 151 427 186 101.6 58.7 90.5 98.4 – 3/4 ​ Colour code: HD-GARANT ​NC-HOLEX 1212
