Centre jaw piece
Application: For multiple clamping. ing
f clamp
Components of different lengths can also be clamped. e d ove rview o X-Team b
tail ent
For a dees, see the curr rochure.
rang lementary b
supp h


l
Application example ​ 36 1111

for type 0 1S 1 2
36 1111 Centre jaw eShop eShop eShop eShop
31O


b mm 100 125 125 125
h mm 85 77.5 117.5 147.5
l mm 80 90 90 90
suitable for colour code
Base rails piece

Fully hardened and ground. Laser engraved scale for prepositioning the clamping claws.
Side groove for steplessly adjustable clamps and transverse slots for alignment
on the machine table.
Size 450; 550 – GARANT ZeroClamp bores drilled as standard. Pitch 200 mm. _450
Suitable for: Clamping modules No. 361105 − 361110.
Size 360H – Round table ⌀ 320 mm. Attachment via stepless adjustable clamps and T-slot.
Optional extras: Clamping claws No. 361165, adapter plate for GARANT ZeroClamp No. 361170, _360H
clamping studs No. 360025 size 18M16 and size 18M16/138.
Note: GARANT ZeroClamp holes available on request from size 650.
See No. 375365 for suitable T-nuts. H
20H7 M16
B
L

Type 360 360H 440 520 450 550 650 850 1050
36 1115 Base rail eShop eShop eShop eShop eShop eShop eShop eShop eShop
31O


L mm 362 362 442 522 454 554 654 854 1054
B mm 100 100 100 100 125 125 125 125 125
H mm 40 40 40 40 48 48 48 48 48
Weight kg 8.5 8.5 10.5 12.5 17 21 25 32 40
Number of ZC holes 2 – 5 3 5 3 on request on request on request
suitable for colour code
Spindles piece
Trapezoidal spindle for optimal force transfer.
Suitable for: Clamping modules No. 361105 − 361110.
Application: TR14 and TR16 for external clamping, TR14I and TR16I for internal clamping.
Optional extras: Spindle extensions No. 361120, torque wrench No. 656050 120. 36 1119_TR16
2AF
Size TR14 – Hexagon bit socket No. 643329 8.
1AF
Size TR16 – Hexagon bit socket No. 643329 10.
Note: Spare parts for spindles No. 361176, 361177 and 361178.

36 1119_TR14I
Type TR14 TR14I TR16 TR16I
36 1119 Spindle eShop eShop eShop eShop
31O


2AF
⌀ D mm 34 34 40 40
AF1 8 10 10 13
AF2 27 27 30 30
L mm 201.1 201.1 229.6 229.6
suitable for colour code
Spindle extensions piece 36 1120
36 Suitable for: Spindle No. 361119.
Type 40 80 160 50 100 200 400
36 1120 Spindle extension eShop eShop eShop eShop eShop eShop eShop
31O


⌀ D mm 30 30 30 34 34 34 34
AF2 27 27 27 30 30 30 30
L mm 50.4 90.4 170.4 61.9 111.9 211.9 411.9
suitable for colour code
Colour code: Xpent0 Xpent1-2
