Accessories for clamping jaws

Suitable for: Parallel jaw No. 360085 and fixed jaw No. 360086. Size 48NF – No. 360084 size 48, 360086 size 48 Size 80; 80ST – No. 360084; 360085; 360086.

Application: For clamping individual workpiece contours. 36 0092 36 0092_80 Jaw width

mm Gripper front jaw 36 0092_80ST

48NF (eShop) 80 eShop 80ST eShop Jaw width / jaw height 36 0093 4 mm Magnetic strip

74/10 eShop 36 0093_74/15

74/15 eShop

74/20 eShop 36 0093_74/30

74/25 eShop 74/30 eShop

Version 36 0094 Version

Component backstop

Accessories for clamping rails 80 mm and 120 mm

Suitable for: Clamping rail No. 360080 and No. 360110.

Application: For conventional fastening to the machine table.

36 0127 Clamping claw set 36 0127

6 pieces eShop

Multi-point clamping rails 120 mm - accessories

• All functional faces precision ground, pairing accuracy 0.03 mm.
• Base rail and jaws case hardened.
• Compact modular design, high clamping force up to 40 kN, maximum tightening torque 50 Nm.
• Attachment hole pattern for GARANT ZeroClamp zero point clamping system (200 mm pitch) as standard, can be mounted on clamping plates or matrix tables, or using table clamps.
• Ruler inset into the top face permits repeatable positioning of the clamp attachments in the serrations of the clamping rail. t
• Variable pitches can be achieved using cross connectors. y for blank par Conventional and grip clamping available. Mainl
• machining!
• Clamping range can be extended individually.
• Easily clamped using a torque wrench.

Application: 5-face machining on multi-axis machining centres.

• As a cost-effective clamping solution for use with the GARANT ZeroClamp zero-point clamping system or with pallet and automated systems, or directly on to the machine table or clamping towers.

Optional extras: Clamping jaw variants, magnetic strip, workpiece backstop see No. 360112 to 360129. Torque wrench No. 656050 size 60, clamping stud No. 360025 size 18M16, clamp No. 360127. L

Clamping jaws

Note: 36 0114/0115 – Torque and clamping force are standard values and are only indicative reference points (material-dependent).

Jaw width mm 120

36 0114 Pull-down jaw eShop

H B 36 0110

AF

36

36 0114 AF 1
