ISO DIN HPC

Face mill arbor – ISO 12164 (DIN 69893) Form A Clamping 40 with 4 tapped holes for drive blocks to DIN 2079. G 2.5

• 25000
• With Balluff/RFID chip bore. min

-1

• Increased collar contact surface. HSK mating faces machined. 30 6550

30 6562–6677/6687/6684/6686/6691 – With cooling channel bores.

Application: For clamping shell end mills and milling cutter heads.

Supplied with: Lock screw.

Optional extras: 30 6563 – Special toggle spanner No. 309840. 30 6550–6557/6566–6691 – Coolant tube No. 309880, socket wrench for coolant tubes No. 309890, toggle spanner No. 309840.

Spigot d mm 16 22 27 32 40 50 60

1 30 6550 HSK-A 63

Face mill arbor A = 100 eShop eShop eShop eShop – – –

30 6562 HSK-A 63

A = 100 eShop eShop eShop eShop eShop – –

30 6557 HSK-A 63

A = 100 eShop eShop eShop eShop eShop – –

30 6563 HSK-F 63

A = 100 eShop eShop eShop eShop eShop – –

30 6566 Face mill arbor HSK-A 63

with cooling channel bore A = 130 eShop eShop eShop eShop eShop – –

30 6575 HSK-A 63

A = 160 eShop eShop eShop eShop – – –

30 6675 HSK-A 100

short eShop eShop eShop eShop eShop eShop eShop

30 6677 HSK-A 100

short eShop eShop eShop eShop eShop eShop –

30 6678 HSK-A 100

Face mill arbor A = 100 eShop eShop eShop eShop eShop eShop –

30 6687 HSK-A 100

A = 100 eShop eShop eShop eShop eShop – –

30 6684 Face mill arbor HSK-A 100

with cooling channel bore A = 100 eShop eShop eShop eShop eShop – –

30 6686 HSK-A 100

A = 130 eShop eShop eShop eShop eShop – –

30 6690 HSK-A 100

• D (30 6550, 30 6562, 30 6557, 30 6566, 30 6575, 30 6675, 30 6678, 30 6684, 30 6686, 30 6690, 30 6691) mm 38 48 60 78 89 120 140
• D (30 6563) mm 38 48 58 78 88 – –
• D (30 6677, 30 6687) mm 38 50 60 78 89 120 –

L mm 17 19 21 24 27 30 40

4

Spare milling cutter lock screw No. 309860 / 309861 16 22 27 32 40 50 60

Lubritool® lubrication device for HSK machine headstocks

For regular lubrication and maintenance of clamping systems in the machine spindle of HSK machines. ailable

ely av ountries:

in the follo, NL, IT

Suitable for: Machine tools with HSK clamping sets – form A, form T, form E. DE, CH, GB , PL, CZ, SK

, FI, SE

Advantage: The right lubricant, at the right time, in the right quantity. BE, DK

• No manual lubrication necessary – and you never have to remember.
• Reduced maintenance time (just 5 seconds). Compact design. Lubrication pulse
• when inserted or

Application: HSK tool clamping systems should be maintained regularly and as exchanged.

instructed by the manufacturer. One cartridge provides approx. 50 lubrication cycles.

Note: Grease cartridge not included in scope of delivery.

Suitable for: Lubrication device No. 304210.

number 1 c

30 4211 Grease cartridge eShop
