Режущие и зажимные инструменты Hoffmann Group 2026 - страница 1007

GBP 57 G 2.5 ≤3µm ISO DIN DIN Form 25000 HSC HPC 12164-1 69882-4 69893 A min-1 Performance milling chuck − ISO 12164 (DIN 69893-1) ■ With RFID/Balluffchip bore. ■ All shanks hard turned. A ■ Supplied with 4 table cooling channel bores. Advantage: ■ No risk of the cutter being pulled out, not even a tug. D D2 D1 ■ Optimised external contour − vibration-damping behaviour. ■ Pleasant handling thanks to the differential thread. ■ Breakage of the milling cutter shank is improbable. ■ Precision version. 30 4450 Application: For clamping tools with side drive flats to DIN 1835 Form B and DIN 6535 Form HB. Best suited for TPC milling or high feed rate applications. No risk of the cutter being pulled out, more precise radial run-out, process reliability! Optional extras: Coolant pipe No. 309880, coolant pipe wrench No. 309890 Clamping ⌀ D1 mm 6 8 10 12 16 20 HSK-A 63 30 4450 eShop eShop eShop eShop eShop eShop 31A Performance milling chuck short with cooling channel HSK-A 100 30 4460 bores eShop eShop eShop eShop eShop eShop 31A short ■ Spring in the base body presses the milling cutter Dimension A (30 4450) mm 65 65 70 80 80 80 or HB shank into the correct position. Dimension A (30 4460) mm 80 80 80 85 100 100 ■ Contact piece on the tightening screw holds ⌀ D (30 4450) mm 26.5 29 36.5 43 48.5 52 the milling cutter in the HB face. ⌀ D (30 4460) mm 27.5 30 37 43 50 53.5 ⌀ D2 mm 22.5 25 32 37.5 43 46.5 G 2.5 ≤3µm ISO DIN Form 25000 HSC HPC 12164-1 69893 A min-1 HiRunER Precision ER collet chuck − ISO 12164 (DIN 69893) External and internal tapers are ground. All shanks are hard turned for smooth running. Including RFID/ HiRunER Standard ER chuck Balluffchip bore, high-performance clamping nut up to 25000 rpm. ■ Collet is fully seated in ■ Collet is not inserted Advantage: ■ Excellent concentricity in the system (chuck + collet + clamping nut), the chuck 100 % in the chuck. 3 µm radial run-out with a 2 µm collet, 6 µm radial run-out with a 5 µm collet. ■ Higher clamping forces! ■ Improved radial run-out! ■ Extremely strong holding force (up to factor 2 better than the standard ER chuck). ■ Vibration reduction effect due to 2-part clamping nut (one part for mini version). Application: For clamping tools with plain shank in collets to DIN 6499 - Form A and B. Supplied with: Precision clamping nut. Optional extras: Coolant tube No. 309880, Socket wrench No. 309890, Slide-optimised ER collets Fahrion No. 308901 and 309432. surface treatment Hook wrench No. 628400, or torque wrench No. 309749 or No. 628520. Note: ■ Clamps only nominal ⌀ up to shank ⌀ tolerance h 10. ■ Do not use the clamping nut in combination with a sealing washer. ■ Use the precision collet chuck always in conjunction with the precision clamping nut No. 309617; 309618. ■ Use in combination with Fahrion collets. ■ The blue design ring must be removed for Fahrion HP 2µm ER collets. 30 5523 Ball-bearing-mounted clamping nut for higher tightening torques 300 Standard HiRunER 100 50 for ER collet size 11M 16M 16 20 25 32 40 ER16 ER32 HSK-A 63 30 5523 30 – – eShop eShop eShop eShop eShop 31A short HiRunER precision HSK-A 63 eShop eShop eShop 30 5524 – eShop eShop eShop 31A ER collet chuck medium HSK-A 63 eShop eShop 30 5527 – – – – – 31A A = 160 Clamping range mm 1 – 7 1 – 10 0.5 – 10 1 – 16 1 – 16 2 – 20 3 – 26 Dimension A (30 5523, 30 5527) mm 160 160 75 75 75 75 85 Dimension A (30 5524) mm 100 100 100 – 100 100 120 ⌀ D mm 16 24 34 38 44 52 62 Mini − size 11M/ 16M 30 5524 Spare ER clamping nut No. 309617 – – 16 20 25 32 40 (extremely slim design). Spare ER clamping nut No. 309618 11M 16M – – – – – 1007
