GBP 57 PARTITION WALL SYSTEMS Doors ■ Completely fitted with lock and door furniture. ■ Variable bolt-on door stops. ■ Optionally left or right closing, opening inwards or outwards. ■ Maximum opening angles: 180° outwards, 135° inwards. High-quality door leaf. Now with even more stiffness for resistance to twisting. Post (not shown) also including fastening plates for the elements and anchor dowels for attachment to concrete floors. End post made of square hollow section, 70×40×3 mm with narrow foot-plate and end brace. Intermediate post similar to the end post but fitted with a wide floor-plate and centre plate for elements on each side. Corner post made from square hollow section, 40×40×3 mm, corner plates for 90° connections. T-post like the intermediate post but for additional wall attachment (for building boxes etc.). Wall connection profile of U-section, 40×35×4 mm, drilled for dowel bolts as an alternative to an end post. Vario corner element No. 99 4105 and No. 99 4107 in each case size 500/500 − permit a variable angular setting at partition wall corners. No need for corner posts! Vario element No. 99 4105 and No. 99 4107 in each case size 550 − 950 − can be extended from 550 − 950 mm, as an adjustment element. ■ Conversion kit for double swing doors No. 99 4135 size 2200 − no upper frame brace required. Allows fork-lift truck access. ■ Illustrated T-post − Allow a projection amounting to a depth of 150 mm (external). Compensating height is achieved by means of the Vario element No. 99 4105 and 99 4107, size 550−950. ■ Panelling brace for clean closure of tailor-made wall elements. Types of partition elements: ■ With flat grid mesh of 40 × 40 × 3.8 mm mounted in a 30 mm section frame. ■ With 5 mm acrylic glass and 1.5 mm sheet metal with cross panel. Wall element Sliding doors Issuing element Double swing doors No. 99 4100 No. 99 4116 No. 99 4121 No. 99 4113 99 Post No. 99 4130 size 3 (corner post) 692
