GBP 57 Depth inserts for chipboard shelves laid on the cross-beams ​ Zn Depth inserts with restraint pin, galvanised. Restraint pin Application: To take chipboard shelves. Secures the shelves against slipping. At the same time it increases the load capacity of the chipboard shelf. Type 1100 ​ 99 1410 Pair of depth inserts 99 1410 96O (eShop) for increased load capacity suitable for racking depth mm 1100 Load capacity per pair kg 946 Chipboard shelf with Z-plate ​ Chipboard shelf 38 mm thick, including Z-plate (to stop the chipboard shelf slipping). Application: For storage of loose items. For protection of passages and gangways. suitable for cross beam length mm 2700/50 99 1425 96O Chipboard shelf (eShop) Length mm 2700 Depth mm 1100 Thickness mm 38 suitable for cross beam depth mm 50 Safe working load kg 1350 Detail of the Z-plate Chipboard shelf including depth insert ​ The chipboard shelf is 38 mm thick including the depth insert, giving a load capacity of 2762 kg. The ends of the shelves are flush with the cross beams. Note: The top of the chipboard is flush with the cross beams, so that even if the stores handling equipment is not positioned exactly, the shelf remains undisturbed Type 1100/50 99 1428 96O Chipboard shelf including depth insert (eShop) Length mm 2700 Depth mm 975 Thickness mm 38 Number of depth inserts 4 ​ 99 1428 suitable for racking depth mm 1100 suitable for cross beam depth mm 50 Safe working load kg 2762 Mesh back panels ​ Frame paint finish blue, mesh galvanised. Mesh 50×50×2.5 mm. Suitable for: 99 1450 – Frame profile S610-M18-U. Stand width 76 mm. Pallet racks No. 991202 all sizes; No. 991207 all sizes; No. 991212 sizes 2500, 3000, 3500; No. 991217 sizes 2500, 3000, 3500. 99 1452 – Frame profile S625-A18. Stand width 100 mm. Pallet racks No. 991212 size 4000, 4500, 5000; No. 991217 size 4000, 4500, 5000; No. 991222 all sizes; No. 991227 all sizes. Application: To prevent stored goods falling out into traffic routes and working areas. 99 99 1450 Type 2700×1000 2700×1500 99 1450 96O Mesh back panel for frame profile S610-M18-U (eShop) (eShop) 99 1452 96O Mesh back panel for frame profile S625-A18 (eShop) (eShop) Mesh height mm 1000 1500 suitable for racking bay width mm 2700 Application example 680
