GBP 57 ​Accessories for pallet racking Cross beam pairs ​ Box section, cold-rolled profiles with welded-on engagement posts. Each engagement post has up to 5 sturdy hooks, for optimum weight distribution across the pallet racking stiles. Colour: RAL 2004 pure orange, powder-coated. Supplied with: 2 cross beams for insertion into the frame stiles, each with 2 locking pins. Note: If new cross beams with depth 50 mm are to be combined with the old cross beams with depth 40 mm, they must be ​ 99 1338 fitted in pairs. Cross beam height Cross-beam length mm 2700 mm 99 1338 96O 96O 96O Cross beam pair LNS-DUO 100×50 (eShop) 100 99 1342 Cross beam pair LNS-DUO 110×50 (eShop) 110 99 1346 Cross beam pair EGN-DUO 120×50 (eShop) 120 Load capacity per pair of cross beams (99 1338) kg 1545 ​ Load capacity per pair of cross beams (99 1342) kg 2460 ​ Load capacity per pair of cross beams (99 1346) kg 3060 ​ Insertion stop ​ Application example Zn Insertion stop for single-sided and double sided racking, galvanised. Fastening material. Suitable for: Single and double racking. Application: Prevents accidental insertion beyond the back of the storage space. 99 1370 for pallet projection in suitable for cross beam length mm 2700 mm 99 1370 96O Insertion stop (eShop) 75 Insertion stop Steel panels ​ Zn Steel panels suitable for all types of cross beam, for laying on the cross beams. Secure positioning by end face hooking over the top of the beam. Specification: For instance, storage width 2700 mm requires 9 panels (9×300 mm). Type 1100/A 1100/B 99 1390 96O Steel panels (eShop) (eShop) Material thickness mm 1.25 1.5 Panel height mm 40 ​ 99 1390 Panel width mm 300 suitable for racking depth mm 1100 Safe working load kg 250 320 Depth inserts for mesh crates ​ Zn Depth inserts with lateral flange and insertion stop, galvanised. Application: Depth inserts for mesh crates, containers, and the like. Suitable for 50 mm cross beam width. Type 1100/50 Pair of depth inserts 99 1400 ​ 99 1400 96O (eShop) for mesh crates suitable for racking depth mm 1100 suitable for cross beam depth mm 50 Depth inserts for crossways storage of pallets ​ Zn 99 Depth inserts in flush version. Application: Depth inserts for crossways storage of pallets. At least 2 depth inserts are required per pallet. Type 1100 Pair of depth inserts ​ 99 1405 99 1405 96O (eShop) for crossways storage suitable for racking depth mm 1100 Load capacity per pair kg 946 679
