GBP 57 25 25 Click Zn ​Office racking plug-in system MULTIplus 85 T-profile frame fronts and storage shelves. 99 0590/0591 – Stiffening by cross-strut. Stop strips prevent files or the documents being pushed through. The top shelf has no stop strip. Maximum load capacity: 85 kg per storage shelf. Rack depth 300 mm: at 2300 mm height, takes up to 96 files per bay. 99 0595/0596 – Stiffening by lengthways bars. Centre stop strip prevents files or the documents being pushed through. The top shelf has no centre stop strip. Maximum load capacity: 150 kg per storage shelf. Rack depth 600 mm: Can be accessed from both sides. At 2300 mm height, takes up to 192 files per bay. Description: Assembled size: Basic rack: Nominal length + 60 mm Extension rack: Nominal length +6 mm Overall depth of the rack: Nominal depth + 36 mm Unsupported length: max. 600 mm Note: ■ Racks with a height/depth ratio greater than 4:1 must be secured against tipping over. ■ Floor and wall fastenings are not included. Application example Application example 1 basic rack + 2 extension racks 99 0590 99 0595 99 Detail – stop rail Detail – centre stop Height /storage 99 0590 99 0591 99 0595 99 0596 Assembled size basic rack Assembled size add-on rack Number of shelves 96P 96P 96P 96P shelf width width width Office racking Office racking Office racking Office racking basic rack extension rack basic rack extension rack 99 0590 99 0591 ​ 99 0595 99 0596 Depth Depth Depth Depth mm 300 mm 300 mm 600 mm 600 mm mm mm ​ 2000/1000 (eShop) (eShop) (eShop) (eShop) 1060 1006 6 2300/1000 (eShop) (eShop) (eShop) (eShop) 1060 1006 7 668
