GBP 57 ​Hazardous substance workstations and underbench cabinet Base ​ 400 kg 950- 1100 GridLine Vario workbench consisting of height-adjustable support legs, storage shelf and sheet metal rear panel together with side panels with square holes. Eterlux worktop 50 mm thick, wear-resistant and resistant to oil, grease, weak acids, and alkalis. Colour: Support leg with manual height adjustment, storage shelf and rear panel RAL 7035 light grey, side panel RAL 7016 anthracite powder-coated. 98 1120 Width mm 1500 98 1120 9GG Base hazardous substance workstation (eShop) Height adjustment range mm 950 – 1100 Depth mm 750 Hazardous substance workstations ​ Sturdy aluminium tubular frame. Anodised surface with high resistance to chemicals. ■ Glazed at the sides with 5 mm ESG (tempered safety glass). ■ Exhaust air monitoring and glare-free lighting, with push button for switching on and off. ■ Wired ready to plug in, with 5 m mains cable. ■ Highly efficient hazardous substance capture due to special fresh air curtain technology in the interior. ■ Generous exhaust ducts, resistant to chemicals. ■ Air outlet spigot NW250 in the roof area for connection to the customer’s extraction system. Application example ■ With LED illumination (500 lux on the work surface). Standard: Air quality testing to DIN EN 14 175 part 3 (type approval test procedure for extraction systems, section 5.4, reliability of the retention capacity). Application: Suitable for all refilling, cleaning, and adhesives work with hazardous substances. Hazardous substance workstations ensure a high degree of health and safety protection. Compliance with the workplace concentration limit regulations is ensured since no vapours, gases or suspended solids contaminate the air at the workplace. When used in the intended manner no explosive vapour / air mixtures can form within the cabinet. Supplied with: 98 1130 – Without a work top, ideal for placing on existing workbenches. 98 1132 – With a stainless steel work top. 98 1134 – With a stainless steel work surface, 2 shielded-contact (230V) sockets and a media supply duct. Note: Connection must be made to the customer’s extraction system. 98 1130 Depth 750 mm Width mm 1500 98 1130 96G Hazardous substance workstation Basic Line (eShop) 98 1132 96G Hazardous substance workstation Comfort Line (eShop) 98 1134 96G Hazardous substance workstation High Line (eShop) Height mm 1400 Width mm 1500 Depth mm 750 The principle of air The principle of operation of the curtain Usable height mm 1100 98 circulation in a hazardous of fresh air in the hazardous substance Weight (98 1130) kg 139 substance workstation. workstation. Weight (98 1132, 98 1134) kg 163 Underbench safety cabinet ​ For secure storage of hazardous substances in working rooms, in accordance with regulations. Fire-resistant 90 minutes. Exhaust air connection external ⌀ 50 mm. Standard: to DIN EN 14470-1. 98 1170 96G Underbench safety cabinet (eShop) Height mm 600 Width mm 593 Depth mm 574 Weight kg 122 98 1170 633
