GBP 57 SUPPORT COLUMN FITTINGS AND CNC RACK Support arm bracket with cross brace lighting unit Support columns Perforated panel Tool carrier Pivoting for perforated Multifix perforated panel side panel CNC rack Lighting unit, Perforated panel Tool carrier Storage shelf fixed laterally for perforated panel CNC storage shelf CNC storage shelf Storage shelf Carrier rail for Tool UNIT CNC storage shelves and racks CNC storage shelves ​ A Sheet metal storage shelves with plastic GARANT tool sockets. Front face with square lip for stabilisation. Range of depth adjustment 130 mm. Stops available horizontal 90° and inclined 120° 97 0660 Suitable for: Assembly by insertion in support columns (Group 92), CNC racking No. 970680 and materials supply trolley No. 918590 size 1000 (Group 91). Colour: Light grey RAL 7035, powder-coated. for tool shanks SK30 SK40 SK50 VDI20 VDI30 VDI40 C4 C5 C6 C8 Width 97 0660 (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) 91L 1000 mm CNC storage shelf Width 97 0665 (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) (eShop) 91L 1500 mm Height mm 80 Depth mm 155 Number of tool sockets (97 0660) 21 10 7 23 17 10 9 9 5 5 Number of tool sockets (97 0665) 33 15 11 36 27 15 14 14 9 9 Axial spacing A mm 60 85 115 55 73 85 95 95 150 110 Load capacity when inserted into support columns kg 25 Load capacity in CNC racks and material trolleys kg 50 for tool shanks HSK40 HSK50 HSK63 HSK80 HSK100 97 Width 97 0660 (eShop) (eShop) (eShop) (eShop) (eShop) 91L 1000 mm CNC storage shelf Width 97 0665 (eShop) (eShop) (eShop) (eShop) (eShop) 91L 1500 mm Height mm 80 Depth mm 155 Number of tool sockets (97 0660) 21 20 10 7 7 Number of tool sockets (97 0665) 33 33 15 12 11 Axial spacing A mm 60 80 85 110 120 Load capacity when inserted into support columns kg 25 Load capacity in CNC racks and material trolleys kg 50 Practical examples: CNC storage shelves Advantages: Storage ■ Tools clearly identified and stored safely ■ Protective ■ Space-saving Provision ■ Defined tools ■ Short journeys ■ Quick access 551
