GBP 57 25 Tool24 Smartline drawer issuing system GARANT Tool24 Smartline – now compatible with GridLine. The flexible inventory management system for maximum efficiency: Store, issue and manage machining and assembly NEW tools, measuring tools, personal protection items and a wide range of consumables – all in one system. Thanks to modular extensions, Tool24 can be individually adapted to your requirements. With the freely selectable software packages, you can configure your system exactly to your requirements. Smart. Flexible. Future-proof. Size SG11M – Compatible with the Hoffmann Group Connected software solutions. With this article you are gaining a building block for your digitally networked production. Increased productivity can be achieved together with the respective software module. Colour: Body light grey RAL 7035, doors anthracite RAL 7016, powder-coated. Supplied with: Size SG11M – Master system: Industrial vending cabinet with 11 drawers 26×24 G, 22-inch touchscreen, 2D barcode scanner, RFID reader, PC including BASIC software package, operating system in English. Size SG12 – Extension system: Industrial vending cabinet including GridLine dividing material. Size SG34 – Extension system: Industrial vending cabinet including GridLine dividing material. Note: Cabinet and drawer configurations: Both cabinet sizes, 750 mm x 700 mm = 30x28G (WxD) and 1000 mm x 700 mm = 40x 28G (WxD), can be configured with customisable drawer sizes. Talk to your technical adviser. 15 kg 75 kg 75 kg 75 kg Type SG11M SG12 SG34 Tool24 Smartline cabinet system 97 9002 eShop eShop eShop 9SA including dividing material Storage area m2 4.3 4.7 4.9 Height mm 1250 Width mm 750 750 1000 Depth mm 700 Insert thickness 25 Drawer usable width mm 650 650 200; 900 Drawer usable depth mm 600 Number of drawers Division within a drawer 11 26×24G 12 26×24G 34 8×24G; 36×24G 97 Weight kg 223 214 309 Fitted with: 10 × 75 mm; 32 × 75 mm; 12 × 75 mm Number of drawers × drawer front height 1 × 150 mm 2 × 150 mm ​10 × 951580 75; 30 × 951530 75; 32 × 951580 75; 150 × 951781 75; Content: 110 × 951761 75; 30 × 951781 75; ​12 × 951580 75; 36 × 951530 75; 8 × 951530 150; 4 × 951741 150; ​Dividing material 3 × 951530 150; 11 × 951761 150; 132 × 951761 75; 36 × 951781 75 12 × 951781 150; 2 × 951580 150 3 × 951781 150; 1 × 951580 150 2​ 2-inch touchscreen; 2D barcode scanner; Supplied with: RFID reader; PC including BASIC software – – package; operating system in English Available Drawer width Drawer width drawer heights 26G (650 mm) 8G (200 mm) 36G (900 mm) Front height X SG11M SG12 SG34 50 mm  75 mm     100 mm     125 mm     150 mm     Application example on a Application example on a 200 mm     26×24G drawer (GridLine dividing material: 36×24G drawer 250 mm     rigid foam inlays, small parts storage bins, (long tools up to 900 mm). 300 mm     slotted dividers with divider inserts). Usable height = front height – 25 mm 535
