для обработки деталей малого размера 2-Х ЗУБАЯ, ПЛОСКИЙ ТОРЕЦ 1СВЕРХДЛИННАЯ ШЕЙКА, МАЛЫЙ ДИАМЕТР
ТИП 7N22
D ( е8 )
0.4
Глубина
2
d
3
D1
0.36
Длина
резания
0.6
Длина
инструмента
38
ТИП ФРЕЗЫ
Чш) ЧД)
'^
7N2200400
0.4
0.5
4
2
3
3
0.36
0.45
0.6
0.7
38
38
7N2200410
7N2200500
> ) '57)
0.5
0.5
4
6
3
3
0.45
0.45
0.7
0.7
38
38
7N2200510
7N2200520
TiAIN RJ )
0.6 2 3 0.55 0.9 38 7N2200600
0.6 4 3 0.55 0.9 38 7N2200610
0.6 6 3 0.55 0.9 38 7N2200620
0.7 2 4 0.65 1 50 7N2200701
0.7 4 4 0.65 1 50 7N2200711
0.7 6 4 0.65 1 50 7N2200721
0.8 4 4 0.75 1.2 50 7N2200801
0.8
0.8
6
8
4
4
0.75
0.75
1.2
1.2
50
50
7N2200811
7N2200821
ГРАФИ ?)
0.9 6 4 0.85 1.35 50 7N2200901
ST>45 HRc )
0.9 8 4 0.85 1.35 50 7N2200911
0.9 10 4 0.85 1.35 50 7N2200921
1 6 4 0.97 1.5 50 7N2201001 30<ST<45 HRc)
1 8 4 0.95 1.5 50 7N2201011
1 10 4 0.95 1.5 50 7N2201021 # 30>ST HRc j < -8- g н
1 12 4 0.93 1.5 50 7N2201031
1.2 6 4 1.17 1.5 50 7N2201201
- w Q) T3
О ГО la
1.2 8 4 1.15 1.8 50 7N2201211
z EIо
"О E 1
1.2 10 4 1.15 1.8 50 7N2201221 CD
1.2 12 4 1.13 1.8 50 7N2201231 C
C/>
1.4
1.4
1.4
6
8
10
4
4
4
1.37
1.35
1.35
2.1
2.1
2.1
50
50
50
7N2201401
7N2201411
7N2201421
-J
Длина
резания
i
1.4 12 4 1.33 2.1 50 7N2201431 Глубина
Длина инструмента
1.4 16 4 1.31 2.1 50 7N2201441
1.5 6 4 1.47 2.3 50 7N2201501
1.5 10 4 1.45 2.3 50 7N2201511
1.5 12 4 1.43 2.3 50 7N2201521
1.5 16 4 1.41 2.3 50 7N2201531
1.5 18 4 1.41 2.3 63 7N2201541
1.5 20 4 1.39 2.3 63 7N2201551
1.6 6 4 1.57 2.4 50 7N2201601
1.6 10 4 1.55 2.4 50 7N2201611
1.6 12 4 1.53 2.4 50 7N2201621
1.6 16 4 1.51 2.4 50 7N2201631
1.6 20 4 1.49 2.4 63 7N2201641
1.7 6 4 1.67 2.6 50 7N2201701
1.7 10 4 1.65 2.6 50 7N2201711
1.7 12 4 1.63 2.6 50 7N2201721
1.7 16 4 1.61 2.6 50 7N2201731
1.7 20 4 1.59 2.6 63 7N2201741
1.8 6 4 1.77 2.7 50 7N2201801
1.8 10 4 1.75 2.7 50 7N2201811
1.8 12 4 1.73 2.7 50 7N2201821
1.8 16 4 1.71 2.7 50 7N2201831
1.8 20 4 1.69 2.7 50 7N2201841
1.9 6 4 1.87 2.8 50 7N2201901
1.9 10 4 1.85 2.8 50 7N2201911
1.9 12 4 1.83 2.8 50 7N2201921
1.9 16 4 1.81 2.8 50 7N2201931
1.9 20 4 1.79 2.8 63 7N2201941
2 6 4 1.97 3 50 7N2202001
2 10 4 1.95 3 50 7N2202011
2 16 4 1.91 3 50 7N2202021
2 20 4 1.89 3 63 7N2202031
2 30 4 1.89 3 75 7N2202041
