| no. = Guhring no. + Code-no. | d3 | Zylinderschaft Gu Discou straight shank | hring no. nt group | 4109 140 | ||||
| er | DIN 6535-HE DIN 6535 HE | |||||||
| Ord | l4 | |||||||
| 1 | h6 | |||||||
| l1 with d no. 4111, s | h d rilling insert Guhr ee h and l4 dime | l2 ing no. 411 nsions pag | l1 2, 4113 or 41 e 8 to 11! | l3 14 only. Wit | d2 h pilot insert G | uhring | ||
| Code no. | Holder size | d1 mm | d2h6 mm | d3 mm | incl. WP l1 mm | l2 max mm | l3 mm | Availability |
| 11,000 | 110 | 11.00 - 11.49 | 12.00 | 10.70 | 147.00 | 82.60 | 45.00 | l |
| 11,005 11,500 | 110 115 | 11.00 - 11.49 11.50 - 11.99 | 12.70 12.00 | 10.70 11.20 | 147.00 151.00 | 82.60 86.10 | 45.00 45.00 | l l |
| 11,505 12000 | 115 120 | 11.50 - 11.99 12.00 - 12.49 | 12.70 12.00 | 11.20 11.70 | 151.00 156.00 | 86.10 89.70 | 45.00 45.00 | l l |
| , 12,005 | 120 | 12.00 - 12.49 | 12.70 | 11.70 | 156.00 | 89.70 | 45.00 | l |
| 12,500 | 125 | 12.50 - 12.99 | 14.00 | 12.20 | 160.00 | 93.30 | 45.00 | l |
| 12,505 13000 | 125 130 | 12.50 - 12.99 1300 1349 | 15.875 1400 | 12.20 1270 | 160.00 16400 | 93.30 9690 | 45.00 4500 | l l |
| , 13,005 | 130 | . - . 13.00 - 13.49 | . 15.875 | . 12.70 | . 164.00 | . 96.90 | . 45.00 | l |
| 13,500 | 135 | 13.50 - 13.99 | 14.00 | 13.20 | 169.00 | 100.60 | 45.00 | l |
| 13,505 | 135 | 13.50 - 13.99 | 15.875 | 13.20 | 169.00 | 100.60 | 45.00 | l |
| 14,000 | 140 | 14.00 - 14.49 | 14.00 | 13.70 | 173.00 | 104.20 | 45.00 | l |
| 14,005 | 140 | 14.00 - 14.49 | 15.875 | 13.70 | 173.00 | 104.20 | 45.00 | l |
| 14500 | 145 | 1450 - 1499 | 1600 | 1420 | 18000 | 10780 | 4800 | l |
| , 14,505 | 145 | . . 14.50 - 14.99 | . 15.875 | . 14.20 | . 180.00 | . 107.80 | . 48.00 | l |
| 15,000 | 150 | 15.00 - 15.49 | 16.00 | 14.70 | 185.00 | 111.30 | 48.00 | l |
| 15,005 | 150 | 15.00 - 15.49 | 15.875 | 14.70 | 185.00 | 111.30 | 48.00 | l |
| 15,500 15,505 | 155 155 | 15.50 - 15.99 15.50 - 15.99 | 16.00 15.875 | 15.20 15.20 | 189.00 189.00 | 114.90 114.90 | 48.00 48.00 | l l |
| 16000 | 160 | 1600 - 1649 | 1600 | 1570 | 19300 | 11890 | 4800 | l |
| , 16,005 | 160 | . . 16.00 - 16.49 | . 15.875 | . 15.70 | . 193.00 | . 118.90 | . 48.00 | l |
| 16,500 | 165 | 16.50 - 16.99 | 18.00 | 16.20 | 198.00 | 122.10 | 48.00 | l |
| 16,505 | 165 | 16.50 - 16.99 | 19.05 | 16.20 | 198.00 | 122.10 | 48.00 | l |
| 17,000 17,005 | 170 170 | 17.00 - 17.49 17.00 - 17.49 | 18.00 19.05 | 16.70 16.70 | 202.00 202.00 | 125.80 125.80 | 48.00 48.00 | l l |
| 17500 | 175 | 1750 - 1799 | 1800 | 1720 | 20600 | 12940 | 4800 | l |
| , 17,505 | 175 | . . 17.50 - 17.99 | . 19.05 | . 17.20 | . 206.00 | . 129.40 | . 48.00 | l |
| 18,000 18005 | 180 180 | 18.00 - 18.49 1800 - 1849 | 18.00 1905 | 17.70 1770 | 211.00 21100 | 132.90 13290 | 48.00 4800 | l l |
| , 18,500 | 185 | . . 18.50 - 18.99 | . 20.00 | . 18.20 | . 217.00 | . 136.50 | . 50.00 | l |
| 18,505 | 185 | 18.50 - 18.99 | 19.05 | 18.20 | 217.00 | 136.50 | 50.00 | l |
| 19000 | 190 | 19.00 - 19.49 | 20.00 | 18.70 | 221.00 | 140.10 | 50.00 | l |
| , 19,005 | 190 | 19.00 - 19.49 | 19.05 | 18.70 | 221.00 | 140.10 | 50.00 | l |
| 19,500 | 195 | 19.50 - 19.99 | 20.00 | 19.20 | 226.00 | 143.70 | 50.00 | l |
| 19,505 20000 | 195 200 | 19.50 - 19.99 2000 2049 | 19.05 2000 | 19.20 1970 | 226.00 23000 | 143.70 14730 | 50.00 000 | l |
| , 20,005 | 200 | . - . 20.00 - 20.49 | . 19.05 | . 19.70 | . 230.00 | . 147.30 | 5. 50.00 | l l |
| 20,500 20,505 | 205 205 | 20.50 - 20.99 20.50 - 20.99 | 25.00 25.40 | 20.20 20.20 | 243.00 243.00 | 151.00 151.00 | 56.00 56.00 | l l |
| 21,000 21,005 | 210 210 | 21.00 - 21.49 21.00-21.49 | 25.00 25.40 | 20.70 20.70 | 247.00 247.00 | 154.60 154.60 | 56.00 56.00 | l l |
