| Артикул № Группа скидок | 9651 159 | |||
| Направление резания | R | |||
| d1 | l1 | l2 | ||
| EUR/шт | ||||
| mm | inch | mm | mm | . |
| 8,700 | 125,000 | 81,000 | 6,10 | |
| 8,730 | 11/32 | 125,000 | 81,000 | 7,70 |
| 8,800 | 125,000 | 81,000 | 7,10 | |
| 8,900 | 125,000 | 81,000 | 6,50 | |
| 9,000 | 125,000 | 81,000 | 5,60 | |
| 9,100 | 125,000 | 81,000 | 7,40 | |
| 9,130 | 23/64 | 125,000 | 81,000 | 7,40 |
| 9,200 | 125,000 | 81,000 | 6,60 | |
| 9,300 | 125,000 | 81,000 | 7,60 | |
| 9,400 | 125,000 | 81,000 | 6,80 | |
| 9,500 9,520 | 3/8 | 125,000 133,000 | 81,000 87,000 | 6,40 7,60 |
| 9,600 | 133,000 | 87,000 | 7,40 | |
| 9,700 | 133,000 | 87,000 | 7,60 | |
| 9,800 | 133,000 | 87,000 | 9,10 | |
| 9,900 | 133,000 | 87,000 | 8,00 | |
| 9,920 | 25/64 | 133,000 | 87,000 | 10,30 |
| 10,000 | 133,000 | 87,000 | 7,20 | |
| 10,100 | 133,000 | 87,000 | 8,50 | |
| 10,200 | 133,000 | 87,000 | 8,50 | |
| 10,300 | 133,000 | 87,000 | 10,50 | |
| 10,320 | 13/32 | 133,000 | 87,000 | 9,30 |
| 10,400 | 133,000 | 87,000 | 10,50 | |
| 10,500 | 133,000 | 87,000 | 8,70 | |
| 10,600 | 133,000 | 87,000 | 11,00 | |
| 10,700 | 142,000 | 94,000 | 14,00 | |
| 10,720 | 27/64 | 142,000 | 94,000 | 13,40 |
| 10,800 | 142,000 | 94,000 | 12,50 | |
| 10,900 | 142,000 | 94,000 | 13,70 | |
| 11,000 | 142,000 | 94,000 | 10,10 | |
| 11,100 | 142,000 | 94,000 | 13,10 | |
| 11,110 | 7/16 | 142,000 | 94,000 | 13,70 |
| 11,200 | 142,000 | 94,000 | 12,80 | |
| 11,300 | 142,000 | 94,000 | 13,90 | |
| 11,400 | 142,000 | 94,000 | 13,90 | |
| 11,500 | 142,000 | 94,000 | 12,80 | |
| 11,510 | 29/64 | 142,000 | 94,000 | 12,80 |
| 11,600 | 142,000 | 94,000 | 13,90 | |
| 11,700 | 142,000 | 94,000 | 14,00 | |
| 11,800 | 142,000 | 94,000 | 14,00 | |
| 11,900 | 151,000 | 101,000 | 17,10 | |
| 11,910 | 15/32 | 151,000 | 101,000 | 13,90 |
| 12,000 | 151,000 | 101,000 | 12,50 | |
| 12,100 | 151,000 | 101,000 | 16,70 | |
| 12,200 | 151,000 | 101,000 | 16,70 | |
| 12,300 | 31/64 | 151,000 | 101,000 | 15,60 |
| 12,400 | 151,000 | 101,000 | 18,30 | |
| 12,500 | 151,000 | 101,000 | 14,80 | |
| 12,600 | 151,000 | 101,000 | 19,60 | |
| 12,700 | 1/2 | 151,000 | 101,000 | 18,00 |
| 12,800 | 151,000 | 101,000 | 18,70 | |
| 12,900 | 151,000 | 101,000 | 22,30 | |
| 13000 | 151000 | 101000 | 1600 | |
| , 13,100 | 33/64 | , 151,000 | , 101,000 | , 19,20 |
| 13,200 | 151,000 | 101,000 | 21,80 | |
| 13,250 | 160,000 | 108,000 | 26,40 | |
| 13,300 | 160,000 | 108,000 | 28,50 | |
| 13,400 | 160,000 | 108,000 | 28,50 | |
| 13,490 13,500 | 17/32 | 160,000 160,000 | 108,000 108,000 | 19,50 20,60 |
