1×d1 d1 1,5×d1 λ d2 R Solid carbide End mills AL 345 / R345 For machining aluminium alloys and other non-ferrous materials AL 345 345 R345 R345 Z=3 l 45° VHM l2 TB l1 P M K P M K P M K P M K Workpiece material N S H N S H N S H N S H Shank Tool material VHM VHM VHM VHM Coating TB TB TB TB Corner type d1 d2 l1 l2 Z R INDEX 14 14 83 32 3 0,5 M9-34B700-0140 M9-34B700-0140-B M9-34B701-0140 M9-34B701-0140-B Tolerancja 14 14 83 32 3 1 - - M9-34B703-0140 M9-34B703-0140-B 16 16 92 36 3 0,5 M9-34B700-0160 M9-34B700-0160-B M9-34B701-0160 M9-34B701-0160-B 16 16 92 36 3 1 - - M9-34B703-0160 M9-34B703-0160-B 16 16 92 36 3 2 -1616923632,5- -- M9-34B705-0160 M9-34B705-0160-BM9-34B706-0160M9-34B706-0160-B7 16 16 92 36 3 3 - - M9-34B707-0160 M9-34B707-0160-B 18 18 92 45 3 1 M9-34B700-0180 M9-34B700-0180-B M9-34B703-0180 M9-34B703-0180-B 20 20 104 50 3 1 M9-34B700-0200 M9-34B700-0200-B M9-34B703-0200 M9-34B703-0200-B 20 20 104 50 3 2 - - M9-34B705-0200 M9-34B705-0200-B 20 20 104 50 3 3 - - M9-34B707-0200 M9-34B707-0200-B 20 20 104 50 3 4 - - M9-34B708-0200 M9-34B708-0200-B d1 [mm] Vc ISO [m/min] 3 4 5 6 8 10 12 14 16 18 20 fz [mm] fz [mm] fz [mm] fz [mm] fz [mm] fz [mm] fz [mm] fz [mm] fz [mm] fz [mm] fz [mm] N1-N4 350-450 0,020 0,030 0,054 0,069 0,085 0,100 0,115 0,135 0,150 0,200 0,220 N N7-N9 160-280 0,020 0,030 0,040 0,055 0,070 0,090 0,095 0,105 0,120 0,140 0,150 1×d1 0,5×d1 Example of orderM9-34B701-0140 R - for tools with corner radius Another tool dimensionsavailable on request207 AL R345 14x14x32x83 R0,5 VHM TB
