Auskragung (L1) bis 7x D
grooving, boring and profiling grooving D min. 5.0 mm
starting at Ø 0.2 mm depth of groove t max. 1.0 mm overhang length (L1) up to 7x D
| Rechts (R): w Links (L): spi a f | ie gezeichne egelbildlich b | t t max. | L1 | L | righth leftha | and (R): nd versio | as shown n (L): mirr | or image d h6 D min. | ||||
| Bestellnummer part number Abmessunge | n in mm | b +0.05 | b (inch) | f | a | L | L1 | t max. dimen | D min. sions in | Ø d h6 mm | K10F CN45F AL41F P07C | Klemmhalter Typ toolholder type |
| R/L 005.01 | 00-10 | 1.0 | 1.9 | 4.4 | 25 | 10 | 1.0 | 5.0 | 5.0 | | ||
| R/L 005.01 | 00-15 | 1.0 | 1.9 | 4.4 | 30 | 15 | 1.0 | 5.0 | 5.0 | | ||
| R/L 005.01 | 00-20 | 1.0 | 1.9 | 4.4 | 35 | 20 | 1.0 | 5.0 | 5.0 | | ||
| R/L 005.01 | 00-25 | 1.0 | 1.9 | 4.4 | 40 | 25 | 1.0 | 5.0 | 5.0 | | ||
| R/L 005.01 | 00-30 | 1.0 | 1.9 | 4.4 | 45 | 30 | 1.0 | 5.0 | 5.0 | | ||
| R/L 005.01 R/L 005.01 | 00-35 17-30 | 1.0 1.17 | 0.046 | 1.9 " 1.9 | 4.4 4.4 | 50 45 | 35 30 | 1.0 1.0 | 5.0 5.0 | 5.0 5.0 | | 645.∙∙∙ 650.∙∙∙ ∙∙∙.5 |
| R/L 005.01 | 50-10 | 1.5 | 1.9 | 4.4 | 25 | 10 | 1.0 | 5.0 | 5.0 | | ||
| R/L 005.01 | 50-15 | 1.5 | 1.9 | 4.4 | 30 | 15 | 1.0 | 5.0 | 5.0 | | ||
| R/L 005.01 | 50-20 | 1.5 | 1.9 | 4.4 | 35 | 20 | 1.0 | 5.0 | 5.0 | | ||
| R/L 005.01 | 50-25 | 1.5 | 1.9 | 4.4 | 40 | 25 | 1.0 | 5.0 | 5.0 | | ||
| R/L 005.01 ↳ ... | 50-30 | 1.5 | 1.9 | 4.4 | 45 | 30 | 1.0 | 5.0 | 5.0 | |
