groove milling by circular	for circlip grooves DIN 471 / 472	D min. 18 mm
interpolation	and groove milling general use	t max. ≤ 3.5

DS t max. S X Fräserschaft shank face	b R R	X	Beispiel exempl	m zeichnung ary application
Abmessungen in mm Bestellnummer part number D min. Nut-Maß m groove dim. m DIN 471 / DIN 472 S	R Ø DS	dimensions b +0.02 ( b -0.02)	in mm b (inch) t max.	Zähnezahl number of teeth K10F AL41F P18C für Fräserschaft for milling shank
Z18.0070.00 18 0.7 5.6 Z18.0080.00 18 0.8 5.6 Z18.0090.00 18 0.9 5.6 Z18.0110.00 18 1.1 5.8 Z18.0117.00 18 - - 5.8 Z18.0130.00 18 1.3 5.8 Z18.0142.01 18 - - 5.8 Z18.0150.00 18 - - 5.8 Z18.0157.02 18 - - 5.8 Z18.0160.00 18 1.6 5.8 ↳ ...	- 17.7 - 17.7 - 17.7 - 17.7 - 17.7 0.1 17.7 0.1 17.7 0.2 17.7 0.2 17.7 0.1 17.7	0.74 0.84 0.94 1.21 1.17 1.41 1.42 1.50 1.57 1.71	1.5 1.7 1.9 3.5 0.046" 3.5 3.5 0.056" 3.5 3.5 0.062" 3.5 3.5	3  ZH18.∙∙∙ 3  3  3  3  3  3  3  3  3 
