| groove milling by circular | for circlip grooves DIN 471 / 472 | D min. 10 mm |
| interpolation | and groove milling general use | t max. = 1.5 |
X
t max.
Fräserschaft
shank face
R
R
X m
Beispielzeichnung exemplary application
Abmessungen in mm dimensions in mm
| Z10.0070.00 | 10 | 0.7 | 3.4 | - | 9.7 | 0.74* | 1.5 | 3 | | |
| Z10.0080.00 | 10 | 0.8 | 3.4 | - | 9.7 | 0.84* | 1.5 | 3 | | |
| Z10.0090.00 | 10 | 0.9 | 3.4 | - | 9.7 | 0.94* | 1.5 | 3 | | |
| Z10.0100.00 | 10 | - | - | 3.4 | 0.1 | 9.7 | 1.00 | 1.5 | 3 | |
| Z10.0110.00 | 10 | 1.1 | 3.5 | - | 9.7 | 1.21* | 1.5 | 3 | | |
| ZH10.∙∙∙ | ||||||||||
| Z10.0130.00 | 10 | 1.3 | 3.5 | 0.1 | 9.7 | 1.41* | 1.5 | 3 | | |
| Z10.0150.00 | 10 | - | - | 3.5 | 0.2 | 9.7 | 1.50 | 1.5 | 3 | |
| Z10.0160.00 | 10 | 1.6 | 3.5 | 0.1 | 9.7 | 1.71* | 1.5 | 3 | | |
| Z10.0200.00 | 10 | - | - | 3.5 | 0.2 | 9.7 | 2.00 | 1.5 | 3 | |
| Z10.0250.00 | 10 | - | - | 3.5 | 0.2 | 9.7 | 2.50 | 1.5 | 3 | |
