groove milling by circular summary interpolation

Schneideinsatz Gewindefräsen	inserts thread milling	Maße dimensions	Seite page
... ↴
Typ Z28 metrisches ISO-Gewinde, Teilprofil, innen	metric ISO-thread, partial profile, internal	ab / starting at M33 x 1.0	... 479
Typ Z628 metrisches ISO-Gewinde, Teilprofil, innen	metric ISO-thread, partial profile, internal	ab / starting at M33 x 1.5	... 480
Typ Z622 metrisches ISO-Gewinde, Vollprofil, außen	metric ISO-thread, full profile, external	Steigung 1.5 - 4. pitch 1.5 - 4.0	0 ... 481
Typ Z12 Whitworth- Gewinde Vollprofil, innen	Whitworth thread full profile, internal	ab / starting at G⅜"	... 482
Typ Z614 Whitworth- Gewinde Vollprofil, innen	Whitworth thread full profile, internal	ab / starting at G¾"	... 483
Typ Z16 Whitworth- Gewinde Vollprofil, innen	Whitworth thread full profile, internal	ab / starting at G⅝"	... 484
Typ Z18 Whitworth- Gewinde Vollprofil, innen	Whitworth thread full profile, internal	ab / starting at G¾"	... 485
Typ Z22 Whitworth- Gewinde Vollprofil, innen	Whitworth thread full profile, internal	ab / starting at G1"	... 486
Typ Z622 Whitworth- Gewinde Vollprofil, innen	Whitworth thread full profile, internal	ab / starting at G1"	... 487
