Toleranzklassen H9 / D9
broaching keyways according insert B = 5 - 20
DIN 138 und DIN 6885 depth of groove up to 10 mm, tolerance grade H9 / D9
| L H R R D min. t max. B B < 10 | R R B | t ma D min | x. . L B≥10 | H | |
| Abmessungen in mm Bestellnummer part number Nenngröße nominal size Schneideinsatz nach DIN insert according DIN B | R | L | dimensions in mm t max. H | K10F AL41F P18C für Klemmhalter | for toolholder type |
| NPV.050H.02 5 H9 DIN 6885 5.02 NPV.060H.02 6 6.02 NPV.080H.02 8 8.02 | 0.2 0.2 0.2 | 17.3 17.3 17.3 | 2.7 5.3 3.4 5.3 4.1 5.3 | NHV. NHV. NHV.30.∙∙∙ | 22.∙∙∙ 22.∙∙∙ (NHV.22) |
| NPV.100H.03 10 10.02 | 0.3 | 17.3 | 4.2 5.3 | NHV.30.∙∙∙ | (NHV.22) |
| NPV.120H.03 12 12.03 | 0.3 | 20.1 | 5.7 5.3 | NHV.38.∙∙(N | HV.30/22.∙∙) |
| NPV.050D.02 5 5.05 NPV.060D.02 6 6.05 | 0.2 0.2 | 17.3 17.3 | 2.7 5.3 3.4 5.3 | NHV. NHV. | 22.∙∙∙ 22.∙∙∙ |
| NPV.080D.02 8 8.06 | 0.2 | 17.3 | 4.1 5.3 | NHV.30.∙∙∙ | (NHV.22) |
| D9 NPV.100D.03 10 10.06 | 0.3 | 17.3 | 4.2 5.3 | NHV.30.∙∙∙ | (NHV.22) |
| DIN 6885 Gleitsitz i NPV.120D.03 12 12.08 | 0.3 | 20.1 | 5.7 5.3 | NHV.38.∙∙(N | HV.30/22.∙∙) |
| sliding fit NPV.140D.03 14 14.08 | 0.3 | 20.1 | 7.5 6.3 | NHV.45.∙(NH | V.38/30/22.∙) |
| NPV.160D.03 16 16.08 | 0.3 | 20.1 | 7.5 6.3 | NHV.45.∙(NH | V.38/30/22.∙) |
| NPV.180D.05 18 18.08 | 0.5 | 20.1 | 9.5 6.3 | NHV.45.∙(NH | V.38/30/22.∙) |
| NPV.200D.05 20 20.1 | 0.5 | 20.1 | 10 6.3 | NHV.45.∙(NH | V.38/30/22.∙) |
Klemmhalter in Klammer sind nicht optimal in Please note that toolholders in brackets are not
NPV.050H.02/AL41F NPV.050H.02/AL41F 358
