Toleranzklassen JS9

broaching keyways according insert B = 5 - 20

DIN 138 und DIN 6885 depth of groove up to 10 mm, tolerance grade JS9

L H R R D min. t max. B B < 10	R R B	t ma D min	x. . L H B≥10
Abmessungen in mm Bestellnummer part number Nenngröße nominal size Schneideinsatz nach DIN insert according DIN B	R	L	dimensions in mm t max. H K10F AL41F P18C für Klemmhalter	for toolholder type
NPV.0501.02 5 JS9 DIN 6885 leichter Sitz slightly fit 5.01 NPV.0601.02 6 6.01 NPV.0801.02 8 8.01 NPV.1001.03 10 10.01 NPV.1202.03 12 12.02 NPV.1202.05 12 12.02 NPV.1402.03 14 14.02 NPV.1602.03 16 16.02	0.2 0.2 0.2 0.3 0.3 0.5 0.3 0.3	17.3 17.3 17.3 17.3 20.1 20.1 20.1 20.1	2.7 5.3  NHV. 3.4 5.3  NHV. 4.1 5.3  NHV.30.∙∙∙ 4.2 5.3  NHV.30.∙∙∙ 5.7 5.3  NHV.38.∙∙(N 8.5 5.3  NHV.38.∙∙(N 7.5 6.3  NHV.45.∙(NH 7.5 6.3  NHV.45.∙(NH	22.∙∙∙ 22.∙∙∙ (NHV.22) (NHV.22) HV.30/22.∙∙) HV.30/22.∙∙) V.38/30/22.∙) V.38/30/22.∙)
NPV.1802.05 18 18.02 NPV.2002.05 20 20.02	0.4 0.5	20.1 20.1	9.5 6.3  NHV.45.∙(NH 10 6.3  NHV.45.∙(NH	V.38/30/22.∙) V.38/30/22.∙)

Klemmhalter in Klammer sind nicht optimal in Please note that toolholders in brackets are not

357 NPV.0501.02/AL41F NPV.0501.02/AL41F
