SYSTEM ZTP Einstechen mit zweischneidigen Wendeplatten grooving with two-cutting edges indexable inserts	Typ Stechdrehen ∙∙∙∙ .20 Wendeschneidplatte, mit ebener Spanfläche indexable insert, with flat chipbreaker Stechbreite S 2.0 - 6.0 mm width of groove S 2.0 - 6.0 mm
Wendeschneidplatten sind in rechten und linken Klemmhaltern sowie Bohrstangen verwendbar H L R R S A A	inserts can be used in RH and LH toolholders as well as in boring bars
Abmessungen in mm Bestellnummer part number S +0.05 H ZTP.0200.20 2.0 7.9	dimensions in mm R L K10F CN45F AL41F P07C Klemmhalter Typ toolholder type 0.2 29.9    R/L .212. ∙∙∙∙ .2-D R/L .220. ∙∙∙∙ .2-D R/L .225. ∙∙∙∙ .2-D
ZTP.0300.20 3.0 7.9 ZTP.0400.20 4.0 7.9 ZTP.0500.20 5.0 7.9	R/L .0.428. ∙∙∙∙ .2-D 0.2 29.9    R/L .212. ∙∙∙∙ .3-D R/L .220. ∙∙∙∙ .3-D R/L .225. ∙∙∙∙ .3-D R/L .0.428. ∙∙∙∙ .3-D 0.2 29.9    R/L .212. ∙∙∙∙ .4-D R/L .220. ∙∙∙∙ .4-D R/L .225. ∙∙∙∙ .4-D 0.2 29.9   
ZTP.0600.20 6.0 7.5	R/L .0.428. ∙∙∙∙ .4-D 0.4 29.9    R/L .212. ∙∙∙∙ .6-D R/L .220. ∙∙∙∙ .6-D R/L .225. ∙∙∙∙ .6-D R/L .0.428. ∙∙∙∙ .6-D

ZTP.0200.20/AL41F ZTP.0200.20/AL41F 324
