grooving, boring and profiling type grooving, D min. 11 mm

for circlips DIN 471 / 472 and grooving

Rechts (R): wie gezeichnet Links (L): spiegelbildlich f D min. b t max.		d s Kle too	ri le mmhal lholde	ghthand (R fthand ver ter Stirn r face	): as show sion (L): m seite	n irror image m Beispielzeic exemplary	hnung application
Bestellnummer part number Nut-Maß m groove dim. m DIN 471 / DIN 472 b +0.03 Abmessungen in mm	b (inch)	f	s d	d imensions i	t max. n mm	D min. K10F AL41F P18C	Klemmhalter Typ toolholder type
R/L S011.0070 0.7 0.73 R/L S011.0080 0.8 0.83 R/L S011.0090 0.9 0.93		6.7 6.7 6.7	4.2 4.2 4.2	8 8 8	1.2 1.3 1.5	11  11  11 
R/L S011.0099 - - 0.99	0.039	" 6.7	4.2	8	1.5	11 
R/L S011.0100 - - 1.00		6.7	4.2	8	2.3	11  
R/L S011.0110 1.1 1.20		6.7	4.2	8	2.3	11  
R/L S011.0117 - - 1.17	0.046	“ 6.7	4.2	8	2.3	11 
R/L S011.0130 1.3 1.40 R/L S011.0150 - - 1.50 R/L S011.0157 - - 1.57	0.062	6.7 6.7 “ 6.7	4.2 4.2 4.2	8 8 8	2.3 2.3 2.3	11   11   11 	611
R/L S011.0160 1.6 1.70		6.7	4.2	8	2.3	11  
R/L S011.0200 - - 2.00		6.7	4.2	8	2.3	11  
R/L S011.0238 - - 2.38	0.094	“ 6.7	4.2	8	2.3	11 
R/L S011.0250 - - 2.50 R/L S011.0300 - - 3.00		6.7 6.7	4.2 4.2	8 8	2.3 2.3	11   11  
