Bohrungsbearbeitung	allgemein,	D min. 7 - 20 mm
	Innenfreistiche DIN 509
grooving, boring and profiling	type boring and profiling,	D min. 7 - 20 mm

general, undercuts DIN 509

Rechts (R): wie gezeichnet Links (L): spiegelbildlich f D min. R �� t max. ��	d s	Klem toolh	righ left mhalte older f	thand (R) hand versi r Stirns ace	: as shown on (L): mirror eite	image Beispielzeichnun exemplary appli	g cation
Abmessungen in mm Bestellnummer part number β ɣ R	f	s	dim d	ensions in t max.	mm D min.	K10F AL41F P18C CBN	Klemmhalter Typ toolholder type
R/L S07.4746.02 47° 3° 0.2	4.15	3.5	4.8	1.2	7		607.∙∙∙
R/L S08.4746.01 47° 3° 0.1 R/L S08.4746.02 47° 3° 0.2	4.65 4.65	3.5 3.5	6 6	1.2 1.2	7.8 7.8	 	608.∙∙∙ 608.∙∙∙
R/L S09.4755.02 47° 3° 0.2	5.50	3.5	6.2	1.5	9		609.∙∙∙
R/L S11.4767.02 47° 3° 0.2 R/L S14.4787.02 47° 3° 0.2	6.70 8.70	4.2 5.3	8 9	2.3 4.0	11 13.7	 	611.∙∙∙ 614.∙∙∙
R/L S14.4787.04 47° 3° 0.4	8.70	5.3	9	4.0	13.7		614.∙∙∙
R/L S16.4710.02 47° 3° 0.2	10.2	5.4	11	4.3	15.8		616.∙∙∙
R/L S18.4712.02 47° 3° 0.2 R/L S20.4714.02 47° 3° 0.2	12.0 14.0	5.6 5.6	11 11	6.0 8.0	18 20	 	618.∙∙∙ 618.∙∙∙
R/L S08.2555.02 30° 5° 0.2 R/L S11.2755.02 30° 5° 0.2	4.65 6.70	3.5 4.2	6 8	1.0 2.3	7.8 11	   	608.∙∙∙ 611.∙∙∙
R/L S14.3555.02 30° 5° 0.2 R/L S16.4055.02 30° 5° 0.2	8.70 10.2	5.3 5.4	9 11	4.0 4.3	13.7 15.8	 	614.∙∙∙ 616.∙∙∙
