Bohrungsbearbeitung Trapezgewinde, D min. 7.0 mm
| grooving, boring and profiling | type threading, | D min. 7.0 mm |
| starting at Ø 0.2 mm | trapezoidal thread, | pitch P = 2.0 - 3.0 |
partial profile, internal
L E X
D min. 30°
b
X
L1
Rechts (R): wie gezeichnet righthand (R): as shown Links (L): spiegelbildlich lefthand version (L): mirror image
Abmessungen in mm dimensions in mm
| R/L 007.1220-22 | 2 | 1.25 | 0.75 | 0.6 | 2.8 | 6.3 | 37 | 22 | 7.0 | 7.0 | | |
| R/L 007.1220-30 | 2 | 1.25 | 0.75 | 0.6 | 2.8 | 6.3 | 45 | 30 | 7.0 | 7.0 | | |
| R/L 007.1730-22 | 3 | 1.75 | 1.10 | 1.0 | 2.8 | 6.3 | 37 | 22 | 7.0 | 7.0 | | 670.∙∙∙ 676.∙∙∙ 687.∙∙∙ ∙∙∙.7 |
| R/L 007.1730-30 | 3 | 1.75 | 1.10 | 1.0 | 2.8 | 6.3 | 45 | 30 | 7.0 | 7.0 | |
