ab Ø 0.2 mm	Vollprofil, innen	Steigung P = 0.5 - 1.5
grooving, boring and profiling	type threading,	D min. 2.4 - 7.0 mm
starting at Ø 0.2 mm	metric ISO-thread,	pitch P = 0.5 - 1.5

full profile, internal

	Rechts (R): wie gezeich Links (L): spiegelbildlic a f X	net h L1	L		righthand (R): as shown lefthand version (L): mirror d h6	image D	min. 60° H1 b E X
	Abmessungen in mm Bestellnummer part number	Steigung P pitch P Regelgewinde / standard thread	H1	E b f	dimensions in mm a L L1 D min.	Ø d h6	K10F CN45F AL41F PD2F Klemmhalter Typ toolholder type
neu neu	R/L 102.0205-10 R/L 102.0205-15	0.5 M3 0.5 M3	0.27 0.27	0.24 0.06 0.2 0.24 0.06 0.2	2.2 25 10 2.4 2.2 30 15 2.4	4.0 4.0	 
neu neu	R/L 103.0307-15 R/L 103.0307-20	0.7 M4 0.7 M4	0.38 0.38	0.32 0.09 0.9 0.32 0.09 0.9	2.9 30 15 3.2 2.9 35 20 3.2	4.0 4.0	40.∙∙∙ ∙∙∙.4  
neu	R/L 104.0205-15 R/L 104.0408-15 R/L 104.0408-25	0.5 0.8 M5 0.8 M5	0.27 0.43 0.43	0.35 0.06 1.5 0.5 0.10 1.5 0.5 0.10 1.5	3.5 30 15 4.0 3.5 30 15 4.0 3.5 40 25 4.0	4.0 4.0 4.0	5.∙∙∙ 6   
	R/L 105.0205-15 R/L 105.0407-15	0.5 0.75	0.27 0.40	0.35 0.06 1.9 0.45 0.09 1.9	4.4 30 15 5.0 4.4 30 15 5.0	5.0 5.0	64  
	R/L 105.0408-15	0.8	0.43	0.50 0.10 1.9	4.4 30 15 4.8	5.0	∙∙ 
	R/L 105.0510-15	1.0 M6	0.54	0.55 0.12 1.9	4.4 30 15 4.8	5.0	650.∙ ∙∙∙.5 
neu	R/L 105.0510-20	1.0 M6	0.54	0.55 0.12 1.9	4.4 35 20 4.8	5.0	
neu	R/L 105.0510-25	1.0 M6	0.54	0.55 0.12 1.9	4.4 40 25 4.8	5.0	
neu	R/L 105.0510-30 ↳ ∙∙∙	1.0 M6	0.54	0.55 0.12 1.9	4.4 45 30 4.8	5.0	
