i ISO P M K N S H ? re fmin fmax ap min ap max 2,1 RCMX 1204MOS-321 T9315 ++ – 0,40 1,00 1,0 3,0 0,2 T9325 ++ – 0,40 1,00 1,0 3,0 14° 7,5° T9335 ++ – 0,40 1,00 1,0 3,0 14° 2,7 RCMX 1606MOS-331 T9315 ++ – 0,40 1,20 1,0 4,0 0,2 T9325 ++ – 0,40 1,20 1,0 4,0 14° 7,5° T9335 ++ – 0,40 1,20 1,0 4,0 14° 6630 ++ – 0,40 1,20 1,0 4,0 3,0 RCMX 2006MOS-341 6630 ++ – 0,60 1,20 2,0 5,0 HFC 0,2 6640 ++ – 0,60 1,20 2,0 5,0 14° 7,5° S 14° RCMX 2507MOS-351 6630 ++ – 0,80 1,20 3,0 7,0 0,2 6640 +++ – 0,80 1,20 3,0 7,0 14° 14° RCMX 3209MOS-361 6640 +++ – 0,80 1,50 3,0 8,0 0,35 14° 14° RCMX 2006MO-RF1 T5305 + – 0,45 1,20 1,0 5,0 T9310 ++ – 0,45 1,20 1,0 5,0 T9315 ++ – 0,45 1,20 1,0 5,0 T9316 ++ – 0,45 1,20 1,0 5,0 T9325 ++ – 0,45 1,20 1,0 5,0 0,2 HFC T9335 - – – – – – 14° 14° RCMX 2507MO-RF1 T9310 ++ – 0,60 1,20 1,5 7,0 S T9315 ++ – 0,60 1,20 1,5 7,0 T9316 ++ – 0,60 1,20 1,5 7,0 T9325 ++ – 0,60 1,20 1,5 7,0 T9335 +++ – 0,80 1,20 3,0 7,0 T8345 ++ – 0,80 1,20 3,0 7,0 RCMX 2006MO-RM1 T9310 ++ – 0,50 1,30 1,5 5,0 T9315 ++ – 0,50 1,30 1,5 5,0 T9316 ++ – 0,50 1,30 1,5 5,0 T9325 ++ – 0,50 1,30 1,5 5,0 T9335 ++ – 0,20 0,90 1,5 5,0 HFC RCMX 2507MO-RM1 T9310 ++ – 0,70 1,20 2,0 7,0 0,22 T9315 ++ – 0,70 1,20 2,0 7,0 S 14° 21° T9316 T9325 ++ ++ – – 0,70 0,70 1,20 1,20 2,0 2,0 7,0 7,0 T9335 +++ – 0,60 0,90 2,0 7,0 RCMX 3209MO-RM1 T9310 ++ – 0,80 1,30 2,0 8,0 T9315 ++ – 0,80 1,30 2,0 8,0 T9316 ++ – 0,70 1,50 2,0 8,0 T9325 ++ – 0,80 1,30 2,0 8,0 T9335 +++ – 0,80 1,30 2,0 8,0 RCMX 2507MO-RM2 T9310 ++ – 0,80 1,50 2,0 7,0 T9315 ++ – 0,80 1,50 2,0 7,0 T9316 ++ – 0,80 1,50 2,0 7,0 HFC 0,4 T9325 ++ – 0,80 1,50 2,0 7,0 RCMX 3209MO-RM2 T5315 ++ – 0,80 1,30 2,0 8,0 S 15° 15° T9310 ++ – 0,80 1,30 2,0 8,0 T9315 ++ – 0,80 1,30 2,0 8,0 T9325 ++ – 0,80 1,30 2,0 8,0 T9335 +++ – 0,80 1,50 3,0 8,0 T84
